The 0.3U satellite from Apogeo Space offers exceptional performance in a miniaturized design, optimizing functionality with a highly compact form factor.
0.3U Satellite
The 0.3U satellite from Apogeo Space offers exceptional performance in a miniaturized design, optimizing functionality with a highly compact form factor.
Description
With exceptional performance in a miniaturized design, the 0.3U satellite optimizes functionality with a highly compact form factor, making it ideal for streamlined missions. This flight-proven satellite boasts a TRL 9 rating, ensuring reliability and readiness for deployment. It features a Cubesat specification of 10x10x3 (folded) and 30x10x3 (unfolded), accommodating a payload mass of up to 0.2 Kg. Data buses include 12C and CAN, with user data storage up to 0.5GB. The satellite provides a payload power peak of 6 W and an average of 1-3 W, supported by a 12 Whr battery capacity. Attitude control is managed through Passive and Active ADCS, while primary communication utilizes UHF/VHF protocols such such as LoRa, FSK, and QPSK. Onboard sensors include Sun, Earth, Accelerometer, Gyros, and Magnetometer.
Specifications
| Cubesat Specification (folded) | 10x10x3 |
|---|---|
| Cubesat Specification (unfolded) | 30x10x3 |
| Payload Mass | 0.2 Kg |
| Data Buses | 12C, CAN |
| User data storage | up to 0.5GB |
| Payload Power Peak | 6 W |
| Battery Capacity | 12 Whr |
| Payload Power Average | 1-3 W |
| Attitude | Passive, Active ADCS |
| Primary communication | UHF/VHF |
| Protocols | LoRa, FSK, QPSK |
| Sensors | Sun, Earth, Accelerometer, Gyros, Magnetometer |
