Test Equipment & EGSE

SNG-2500C Satellite News Gathering Spectrum Analyzer

AVCOM of Virginia

Frequency Range5–2300 MHz
Resolution Bandwidth10 kHz, 100 kHz, 300 kHz, 1 MHz
RF Sensitivity>-85 dBm typical

Full-size SNG spectrum analyzer, Tektronix TEK 1705A replacement, 5–2300 MHz with 6 switchable inputs.

Test Equipment & EGSE

SBS2-2150E-RSA Rack-Mount L-Band Beacon Receiver & Spectrum Analyzer

AVCOM of Virginia

Frequency Coverage (L-Band)950–2150 MHz
Frequency Coverage (Reference)8–12 MHz
RF Sensitivity-115 dBm at 10 kHz RBW typical

1RU rack-mount L-band spectrum analyzer (950–2150 MHz) with 75 dB dynamic range and -115 dBm sensitivity.

Test Equipment & EGSE

SA-MOD-1-9-B Embedded Spectrum Analyzer Module

AVCOM of Virginia

Frequency Range (Model 2290)900–2200 MHz
Frequency Range (Model 3040)400–3000 MHz
Frequency Range (Model 6070)70–6000 MHz

Ultra-compact embedded spectrum analyzer module, 3"×3.5"×1", 8-33 VDC, -40 to +70°C, 40,000 ft altitude.

Test Equipment & EGSE

RSA-2500B Rack-Mount Spectrum Analyzer

AVCOM of Virginia

Frequency Range5 MHz–2300 MHz
Span WidthUp to 1300 MHz
Resolution Bandwidth10 kHz, 100 kHz, 300 kHz, 1 MHz

1RU rack-mount spectrum analyzer with up to 6 inputs for remote satellite carrier monitoring via IP.

Test Equipment & EGSE

PSA-4200C Portable C-Band / L-Band Spectrum Analyzer

AVCOM of Virginia

Frequency Range (Input 1)5–2300 MHz
Frequency Range (Input 2)3.8–4.2 GHz
Max Span Width1300 MHz

Portable spectrum analyzer covering 5 MHz–4.2 GHz with two inputs for direct C-Band satellite measurement.

Test Equipment & EGSE

PSA-2500C Portable Spectrum Analyzer

AVCOM of Virginia

Frequency Range5 MHz–2300 MHz
Span WidthUp to 1300 MHz
Resolution Bandwidth10 kHz, 100 kHz, 300 kHz, 1 MHz

Portable spectrum analyzer covering 5 MHz–2300 MHz with Li-Ion battery, for satellite installation and testing.

Test Equipment & EGSE

MSNG-2500C Mini SNG Spectrum Analyzer

AVCOM of Virginia

Frequency Range5–2300 MHz
Span WidthUp to 1300 MHz
Resolution Bandwidth10 kHz, 100 kHz, 300 kHz, 1 MHz

Compact SNG spectrum analyzer for satellite news gathering vehicles, 60% shorter than full-size units.

Test Equipment & EGSE

EVO-RSA (Rev B) Rack-Mount Spectrum Analyzer

AVCOM of Virginia

Frequency Range (Model 2290)900–2200 MHz
Frequency Range (Model 3040)400–3000 MHz
Frequency Range (Model 6070)70–6000 MHz

1RU rack-mount spectrum analyzer, up to 12 inputs, 70–6000 MHz, DSP/FPGA platform with Ethernet/USB.

Test Equipment & EGSE

EVO-CLM (Rev B) Compact Spectrum Analyzer

AVCOM of Virginia

Frequency Range (Model 2290)900–2200 MHz
Frequency Range (Model 3040)400–3000 MHz
Max Span Width1300 MHz

Compact spectrum analyzer built on DSP/FPGA platform, supports Ethernet/USB, 900–3000 MHz or 400–3000 MHz.

Test Equipment & EGSE

DRSA-2500B / TRSA-2500B Dual/Triple Spectrum Analyzer

AVCOM of Virginia

Frequency Range5 MHz – 2,300 MHz
Span WidthUp to 1300 MHz
Resolution Bandwidth10 kHz, 100 kHz, 300 kHz, 1 MHz

Dual or triple embedded spectrum analyzers in 1U rack, for simultaneous multi-carrier satellite signal monitoring.

Ground Segment

ATZK-0020-0100 Ku-Band VSAT Transmitter SSPA

ATCi

Frequency BandKu-Band
Output Power Range20-100 W (custom available)
Weight26-82 lbs

Ku-Band VSAT SSPA transmitter series, 20-100W output, compact and rugged outdoor design.

Ground Segment

ATZC-10-100 C-Band VSAT Transmitter SSPA

ATCi

Frequency BandC-Band
Output Power Range10-100 W (custom available)
Weight26-82 lbs

C-Band VSAT SSPA transmitter series, 10-100W output, rugged outdoor design.

Ground Segment

ATZC-0012 C-Band VSAT Transmitter SSPA

ATCi

Frequency BandC-Band
Weight22 lbs
InputL-Band

Compact C-Band VSAT solid state power amplifier transmitter, lightest unit available at 22 lbs.

Ground Segment

ATCi Parabolic Antenna 4.5m C/Ku-Band Prime Focus Rx

ATCi

Diameter4.5 m
C-Band Gain42.3 dB at 4 GHz
Ku-Band Gain51.1 dB at 12 GHz

4.5m prime focus parabolic receive-only antenna for C and Ku-band satellite communications.

Ground Segment

ATCi Parabolic Antenna 3.7m C/Ku-Band Prime Focus Rx

ATCi

Diameter3.7 m
C-Band Gain42.3 dB at 4 GHz
Ku-Band Gain51.1 dB at 12 GHz

3.7m prime focus parabolic receive-only antenna for C and Ku-band satellite communications.

Software & Services

Phoenix Eye OmniPNT

Miles Space / RocketStar

CapabilityGPS-denied Alternative Positioning, Navigation & Timing (APNT)
Signal sourcesSun, moon, planets, pulsars, satellites, signals of opportunity
Hardware integrationLuneburg lens systems (best results); ESAs with known sideline measurements

GPS-denied Alternative Positioning, Navigation and Timing (APNT) software that determines location using celestial radio sources.

Software & Services

Phoenix Eye WhisperHunter

Miles Space / RocketStar

Target applicationIntelligence, Surveillance & Reconnaissance (ISR)
Problem addressedGrating lobes from carrier phase differences in ESA receivers
BenefitAntenna design freedom, hybrid multi-device meshes, higher signal sensitivity

ISR-focused signal detection software addressing grating-lobe limitations in Electronically Scanned Antenna receivers.

Software & Services

Phoenix Eye SignalBoost

Miles Space / RocketStar

CapabilityLow Probability of Intercept/Detect (LPI/D) communications
Detection thresholdDetects signals tens of dB below the noise floor
OriginAdapted from deep-space communications DSP software

Low Probability of Intercept/Detect (LPI/D) tactical radio communications software adapted from deep-space signal processing technology.
