SBC-1461 Single Board Computer
TRL-9 credit-card-sized single-board computer with 64-bit ARM quad-core at 1.8 GHz, 2 GB ECC SDRAM, 30 GB eMMC, and 10GbE interface for LEO satellites.
Description
The CesiumAstro SBC-1461 is a compact, TRL-9 certified single-board computer designed for LEO satellite missions. Provides reliable onboard compute, data handling, and system control within integrated satellite architectures. Features a 64-bit ARM quad-core Cortex processor at up to 1.8 GHz, 2 GB ECC SDRAM, 30 GB eMMC non-volatile storage, and multiple high-speed interfaces including 10GBASE-KR Ethernet. Ships with an Ubuntu-based Linux OS and GNU toolchain. Designed for 5-7 year mission duration.
Specifications
| Processor | 64-bit ARM quad-core Cortex, 1.4-1.8 GHz |
|---|---|
| SDRAM | 2 GB with ECC |
| Flash | 32 MB |
| FRAM | 256 KB |
| Non-volatile Storage | 30 GB eMMC |
| Interfaces | 1000BASE-T, 10GBASE-KR, SGMII, RS-485, RS-422, JTAG |
| Input Voltage | 10-14 V |
| Power Consumption | <15 W |
| Operating Temperature | -24 to +61 deg C (baseplate) |
| Mass | 116 g |
| Dimensions | 50 x 84 x 13 mm |
| OS | Ubuntu-based Linux |
| TRL | 9 |
| Mission Duration | 5-7 years |
