The Groundcom Dual S/X-band Ground Station System is a precision-engineered, field-proven, and mission-ready solution for simultaneous TT&C and high-rate data downlinks, designed for demanding Earth Observation and research missions.
Dual S/X-band Ground Station System
The Groundcom Dual S/X-band Ground Station System is a precision-engineered, field-proven, and mission-ready solution for simultaneous TT&C and high-rate data downlinks, designed for demanding Earth Observation and research missions.
Description
Groundcom's Dual S/X-band Ground Station System offers dual-band mastery, engineered for simultaneous TT&C (Telemetry, Tracking, and Command) and high-rate data downlinks. These "Plug & Play" dual-band systems eliminate technical friction, providing a professional, vertically integrated gateway for the most demanding Earth Observation and research missions. Available with apertures ranging from 2.4m to 4.5m, the system ensures first contact in under 30 minutes. It combines S-band for rock-solid reliability in critical TT&C with X-band for ultra-fast, high-volume data downlink, ideal for Earth observation and complex payloads. This high-performance dual capability is delivered in one fully autonomous, turnkey system, stopping data bottlenecks. The system provides seamless S-Band (Uplink/Downlink) and X-Band (7.9-8.4GHz Downlink) operations, featuring advanced monopulse tracking for sub-degree accuracy. Its software-defined architecture handles S-band TT&C and high-speed X-band payload data simultaneously, making it fully autonomous and API-driven for complex, data-heavy satellite constellations.
Specifications
| Rx | 7900-8400 MHz |
|---|---|
| Tx | 2025-2120 MHz |
| EIRP | 49 dBW |
| G/T | 24.5 dB/K |
| Dish diameter | 3 m |
| Antenna gain (3m dish) | Xband >45.5 dBi |
| Polarization | RHCP/LHCP - electronically switchable |
