The Hughes self-aligning flat panel electronically steerable antenna (ESA) provides high-performing, global, low-latency connectivity for LEO satellites.
Electronically Steerable Antennas (ESA)
The Hughes self-aligning flat panel electronically steerable antenna (ESA) provides high-performing, global, low-latency connectivity for LEO satellites.
Description
The Hughes Electronically Steerable Antenna (ESA) is a flat panel antenna designed for OneWeb LEO Satellites, offering high-performing, global, low-latency connectivity. These user terminals feature a low-profile, flat panel antenna with a built-in modem, making them lightweight, low-power, weather-tight, and easy to install and maintain. Hughes leverages its expertise in satellite terminal design and integration, having produced over ten million satellite terminals, to engineer these ESA user terminals. The innovative flat panel antenna technology ensures seamless handoffs between satellite beams for uninterrupted connectivity. The Hughes LEO terminal is configured and activated using a dedicated mobile app, providing quick configuration access for both installers and end customers. The ESA is ideal for fixed and mobile deployments requiring low-latency broadband connectivity.
Specifications
| Peak Downlink Data Rate (HL1100W) | up to 75 Mbps |
|---|---|
| Peak Downlink Data Rate (HL1120W) | up to 195 Mbps |
| Peak Uplink Data Rate (HL1100W) | up to 14 Mbps |
| Peak Uplink Data Rate (HL1120W) | up to 32 Mbps |
| ESA Dimensions (HL1100W) | 23.5 in. x 15.8 in x 2.4 in |
| ESA Dimensions (HL1120W) | 23.5 in. × 32.6 in. × 5.4 in. |
| ESA Weight (HL1100W) | 23.34 lb. (10.59 kg) |
| ESA Weight (HL1120W) | 53.2 lbs. (24.13kg) |
| Operating Temp | -40°C to + 55°C |
| Environmental Rating | IP67 |
| Wi-Fi 6 | Included |
| RJ45 GigE Ports | 2 included |
