FANTM-RAiL Deployer
Xtenti
Lightweight, flight-proven smallsat deployer with railed and tabbed interfaces for payloads up to 60 kg.
Typed specifications1 values
Discloses 0 of 17 fields engineers filter by in this category (category median 3).
- Flight heritage
- 100% successful in-space deployment record across multiple missions product page
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier6 lines, in the manufacturer's own wording
- Payload capacity
- Up to 60 kg
- Interface
- Railed and tabbed interfaces, multiple industry-standard sizes
- Compatibility
- Stand-alone on flat launch interface, or containerized inside FANTM-RiDE Dispenser
- Optional accessories
- FANTM-CAGE enclosures and shields for payload protection during processing and launch
- Flight heritage
- 100% successful in-space deployment record across multiple missions
- TRL
- 9 (flight-proven)
About
FANTM-RAiL is Xtenti’s smallsat deployer line, designed as a lightweight, minimalist system for launching and deploying payloads either within a larger FANTM-RiDE Dispenser or stand-alone on a flat launch interface. It offers railed and tabbed interfaces in various sizes that follow industry standards, supporting payloads up to 60 kg, and is tailorable to customer needs with a static launch interface to simplify integration. The design allows non-standard payload dimensions, greater protrusion allowables, and adjustable ejection velocities for mission-specific requirements. Optional FANTM-CAGE enclosures and shields are available to protect payloads during processing and launch. FANTM-RAiL is flight proven, with a 100% successful in-space deployment record across a diverse range of smallsat sizes, and each variant/upgrade is qualified to rigorous industry standards. Xtenti provides hands-on integration support, having integrated satellites on complex multi-manifest, pathfinding first-launch missions.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
