BADGER
AeroVironment (Tomahawk Robotics)
BADGER (Broad Area Deployable Ground terminal enabling Resilient communication) is AeroVironment’s flagship space-domain ground system, packaged in a deployable 20-foot ISO container for rapid field deployment. It is a modular, reconfigurable, large-form-factor digital phased array built for complex SATCOM, telemetry, and electronic warfare missions, using Multi-band/beam Software Defined Antenna technology with proprietary digital beamforming. Key […]
Typed specifications20 values
Discloses 5 of 13 fields engineers filter by in this category (category median 2).
- Frequency bands
- L L/S/C-Band operational frequencies · datasheet p.2 L OPERATIONAL | S L/S/C-Band operational frequencies | S OPERATIONAL | C L/S/C-Band operational frequencies +1
- Data interface
- other digital · datasheet p.2
- Operating temperature
- -40 °C min · datasheet p.2 50 °C max | -40–50 °C
- Offering
- ground station as a service datasheet p.1 other broad area deployable ground terminal (phased array) | antenna hardware
- Antenna type
- phased array datasheet p.1
- Installation
- transportable Deployable 20-Foot ISO Container · datasheet p.2
- Mount / pedestal
- electronic steering scan angle +/-60 degrees · datasheet p.2
- Transmit power
- 2 000 W 2-kilowatt equivalent spatial distributed HPA · datasheet p.2
- Tracking
- autotrack (monopulse) Integrated Complex Mono-pulse Tracking (ICMT) · datasheet p.2 electronic beam steering software defined beam states and targets
- Satellite class
- GEO datasheet p.2
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier9 lines, in the manufacturer's own wording
- Orbital coverage
- GEO / MEO / LEO
- Frequency bands
- L/S/C-Band
- Scan angle
- ±60 degrees
- Simultaneous operations
- 4 TX / 12 RX beams
- Amplifier power
- Distributed 2-kilowatt high-power amplifier
- Form factor
- Deployable 20-foot ISO container
- Operating temperature
- -40°C to +50°C
- Beamforming
- Multi-band/beam Software Defined Antenna with proprietary digital beamforming
- Acquisition & tracking
- Broad Area Automated Acquisition; Integrated Complex Mono-pulse Tracking
About
BADGER (Broad Area Deployable Ground terminal enabling Resilient communication) is AeroVironment’s flagship space-domain ground system, packaged in a deployable 20-foot ISO container for rapid field deployment. It is a modular, reconfigurable, large-form-factor digital phased array built for complex SATCOM, telemetry, and electronic warfare missions, using Multi-band/beam Software Defined Antenna technology with proprietary digital beamforming. Key capabilities include Broad Area Automated Acquisition, Integrated Complex Mono-pulse Tracking, and Frequency Agile Operations, enabling simultaneous support of multiple missions across L/S/C-Band frequencies with a distributed 2-kilowatt high-power amplifier. BADGER can track and communicate with satellites across GEO, MEO, and LEO orbital regimes with a ±60 degree scan angle, supporting 4 simultaneous transmit beams and 12 simultaneous receive beams. It is designed for the U.S. Space Force and allied militaries to maintain resilient command-and-control and communications links with satellites in contested and congested orbital environments. BADGER underpinned AeroVironment’s role in the Space Force’s Satellite Communication Augmentation Resource program; the company received a firm-fixed-price contract option in 2025 for delivery of two BADGER phased array systems.
