0.9 Meter Satcom On-The-Move Antenna (V900)
ALL-SEEING TECHNOLOGY CO., LTD
Flat-array roof-mounted Ku-band SOTM antenna system providing continuous satcom connectivity to moving vehicles.
Typed specifications35 values
Discloses 7 of 10 fields engineers filter by in this category (category median 2).
- Frequency band
- Ku datasheet p.3 Ku Receive | Ku Transmit
- Peak gain
- 38.5+ 20lg(f/12.5GHz) Receive · datasheet p.3 38.5 dBi Receive, printed as 38.5 + 20lg(f/12.5GHz) | 39.5+ 20lg(f/14.25GHz) Transmit | 39.5 dBi Transmit, printed as 39.5 + 20lg(f/14.25GHz)
- Mass
- 98 000 g Antenna only, excluding BUC · datasheet p.3 98 000 g outdoor unit, antenna only, excluding BUC
- Frequency range
- 10 950–12 750 MHz Receive · datasheet p.3 13 750–14 500 MHz Transmit
- Envelope (L×W×H)
- Φ135×75H(cm) datasheet p.3 diameter 135 x 75H (cm) outdoor unit size
- Polarization
- linear datasheet p.3
- Antenna type
- Prime focus antenna datasheet p.3 reflector (parabolic) Antenna type: Prime focus antenna (p.1 calls the V Series a f…
- Supply voltage
- 48 V DC · datasheet p.3 48 V DC 48V | 110–220 V AC 110-220, 50/60 Hz (optional) | 110–220 V AC 50/60Hz (Optional)
- Power consumption
- 650 W ant. · datasheet p.3 650 W continuous power consumption, antenna | 10 W continuous power consumption, IDU | 10 W IDU
- RF connector
- N Electrical interface, Receive · datasheet p.3 N Electrical Interfaces | other Electrical Interfaces (WR75) | waveguide flange WR75, Electrical interface, Transmit
- Connector
- N Electrical Interfaces · datasheet p.3 WR75 Electrical Interfaces
- Beam steering
- mechanical (gimbal) azimuth and elevation turntable with servo drive motor, satco… · datasheet p.3
- Max RF power
- 650 W ant. · datasheet p.3
- Reflector diameter
- 0.9 m Diameter · datasheet p.3
- G/T
- 16.3 dB/K Antenna G/T · datasheet p.3
- EIRP
- 55.5 dBW Uplink EIRP, with ext. 40W BUC · datasheet p.3
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier23 lines, in the manufacturer's own wording
- Diameter
- 0.9 m
- Operating frequency (Receive)
- 10.95-12.75 GHz (Ku Band)
- Operating frequency (Transmit)
- 13.75-14.5 GHz (Ku Band)
- Antenna type
- Prime focus antenna
- Sidelobe pattern
- First side lobe level <= -14 dB
- Gain (Receive)
- 38.5 + 20lg(f/12.5 GHz) dBi
- Gain (Transmit)
- 39.5 + 20lg(f/14.25 GHz) dBi
- Polarization
- Linear
- Antenna g/t
- 16.3 dB/K
- Cross polarization
- >= 35 dB
- Uplink eirp
- 55.5 dB (with ext. 40 W BUC)
- Electrical interfaces
- N (Rx) / WR75 (Tx)
- Power supply
- DC 48 V, AC 110-220V 50/60 Hz (Optional)
- Continuous power consumption
- 650 W (antenna) + 10 W (IDU)
- Azimuth travel range
- 360 deg continuous, automatically adjusted
- Elevation travel range
- 15-90 deg, automatically adjusted
- Polarization travel range
- +/-180 deg, automatically adjusted
- Initial satellite acquisition
- <60 sec, tuned on satellite beacon
- Satellite re-acquisition
- <10 sec (when loss/blockage is <20 min)
- Azimuth tracking accuracy
- 0.2 deg @ 60 deg/s, 200 deg/s^2
- Elevation tracking accuracy
- 0.9 deg @ 45 deg/s, 200 deg/s^2
- Outdoor unit size
- Diameter 135 x 75H cm
- Outdoor unit weight
- 98 kg (antenna only, excluding BUC)
About
The V Series is a waveguide-array-type satcom-on-the-move antenna system built as an integrated unit for mobile satellite communication. It combines fiber-optic gyro inertial navigation with beacon tracking to maintain lock during sharp turns and on bumpy roads, working with all Ku-band communication satellites so the equipped vehicle can continuously and accurately track a satellite during movement, enabling uninterrupted multimedia communication with a central station. The whole system integrates on the antenna turntable for a high-precision, low-profile, rugged, easy-to-install roof-mounted design. After the system starts, acquisition and tracking complete automatically without manual operation, whether the vehicle is moving or stationary; if signal is lost, re-acquisition takes only about 3 seconds, with a maximum transmission data rate of 4 Mbps. The outdoor antenna/turntable mounts on the vehicle roof while the antenna control unit (ACU) is a 1U 19-inch rack-mount unit installed in the vehicle cabin. Configuration includes the antenna/feed system, waveguide/connection cable/slip rings, azimuth-elevation turntable and servo drive, antenna control system, fiber-optic gyro inertial navigation system, and tracking receiver. Available in 0.6m, 0.8m and 0.9m sizes.
