DCM3220 Digital Transceiver
Mercury Systems
The EnsembleSeries™ DCM3220 is an agile, OpenVPX digital transceiver in a 3U form factor designed for SWaP-constrained, rugged environments in applications such as unmanned airborne and naval.
Technical specifications
- FPGA
- Virtex® Ultrascale+™ VU7P
- MPSoC
- Zynq ® Ultrascale+™ ZU11EG
- DSP slices
- 7,488
- Memory
- 8 GB DDR4
- ADC channels
- Two 12-bit
- ADC sampling rate
- 6.4 GSPS
- DAC channels
- Two 12-bit
- DAC sampling rate
- 6.4 GSPS
- FPGA core voltage (PR0)
- +0.85V @80A
- FPGA core voltage (ZYNQ)
- +0.85V @40A
About
The DCM3220 Digital Transceiver offers low-latency, high-instantaneous bandwidth with high analog input/output frequency, operating at rates up to 6.4 GSPS. Its flexible, configurable architecture is created with a combination design that exploits the full volume of the digital transceiver by incorporating advanced conduction cooling technology. This design supports advanced electronic warfare, beam steering, and coherent communication systems. Key features include high spectral density in a 3U OpenVPX form factor, wide IBW with low-latency ADC and DAC performance, and design for system security engineering (SSE). It is a multi-channel, highly configurable Rx/Tx module that is coherent and spectrally pure for EW applications, powered by Virtex® UltraScale+™ FPGA processing. The DCM3220 also supports multi-channel/multi-card synchronization and includes a built-in IPMI controller.
