EHP High Performance Microwave Pyramidal Absorber
ETS-Lindgren
Extra high-performance pyramidal absorber effective from 30MHz to 100GHz — conductive carbon-impregnated urethane foam for chamber wall/floor/ceiling treatment.
Technical specifications
- Frequency range
- 30 MHz-100 GHz
- Power handling
- 1.0 W/in²
- Substrate
- Non-hygroscopic
- Fire rating
- Fire retardant
- Optional treatment
- FlexSorb (improved durability)
About
The EHP Series Extra High Performance Microwave Pyramidal Absorber covers a wide frequency spectrum and is effective at reducing reflections from 30 MHz through 100 GHz. Each piece is fabricated from high-quality urethane foam cut into a precise bun configuration and impregnated with ETS-Lindgren’s proprietary conductive carbon formulation. It is preferred for specular treatment on chamber back walls, side walls, floors, and ceilings, used in military, automotive, and wireless measurement applications. An optional FlexSorb treatment improves durability while retaining the same performance.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
