LNB/LNA Low Noise Amplifiers
EUROSATCOM
Low noise block downconverters and amplifiers for C, Ku, and Ka band satellite receive chains — noise figures as low as 0.22dB.
Typed specifications6 values
Discloses 2 of 10 fields engineers filter by in this category (category median 2).
- Frequency bands
- C LNB · description Ku LNB | Ka LNB
- Frequency range
- 3 400–4 200 MHz description 10 700–12 750 MHz | 17 700–22 200 MHz
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier6 lines, in the manufacturer's own wording
- C band lnb frequency
- 3.4-4.2 GHz
- C band best noise figure
- 0.22 dB (5000R Series)
- KU band lnb frequency
- 10.7-12.75 GHz
- KU band best noise figure
- 0.85 dB (1000DH Series)
- KA band lnb frequency
- 17.7-22.2 GHz
- KA band best noise figure
- 1.3 dB (ACLNBP-Ka Premium)
About
The LNB product line includes C Band LNB (3000 Series, 3000C, 3000R, 3000 BPF, 3200 BPF, 3000X, 5000R series) with frequencies from 3.4-4.2 GHz and noise figures as low as 0.22 dB; Ku Band LNB (1000DH, 1000DX, 1000HU, 1000XDF, 1000XE, 1000XU series) covering 10.7-12.75 GHz with noise figures around 0.85-1 dB; and Ka Band LNB (ACLNBS-Ka, ACLNBP-Ka, ACLNBD-Ka, ACLNBW-Ka series) covering 17.7-22.2 GHz with noise figures of 1.3-1.8 dB.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
