MS3100A 10SL Wall mounting receptacle
Hunan Kaida Space Connectors
A wall mounting receptacle with 5/8-24 UNF A Thread and 5/8-24NEF V Thread.
Technical specifications
- A Thread
- 5/8-24 UNF
- B (Min)
- 9.53
- K Min /Max
- 1.58/3.96
- L Max
- 38.88
- M+0.79/-0.00
- 14.28
- R±0.12
- 18.26
- S±0.79
- 25.40
- T+0.25/-0.12
- 3.05
- V Thread
- 5/8-24NEF
About
The MS3100A 10SL is a wall mounting receptacle designed for electrical connections. It features a 5/8-24 UNF A Thread and a 5/8-24NEF V Thread. The receptacle has a B dimension of 9.53, a K dimension ranging from 1.58 to 3.96, an L dimension of 38.88, an M dimension of 14.28, an R dimension of 18.26, an S dimension of 25.40, and a T dimension of 3.05. This component is part of the MS3100 Class A series.
