MS3100A 12S Wall mounting receptacle
Hunan Kaida Space Connectors
A wall mounting receptacle with 3/4-20 UNEF A Thread and 5/8-24NEF V Thread.
Technical specifications
- A Thread
- 3/4-20 UNEF
- B (Min)
- 9.53
- K Min /Max
- 1.58/3.96
- L Max
- 42.87
- M+0.79/-0.00
- 14.28
- R±0.12
- 20.62
- S±0.79
- 27.79
- T+0.25/-0.12
- 3.05
- V Thread
- 5/8-24NEF
About
The MS3100A 12S is a wall mounting receptacle designed for electrical connections. It features a 3/4-20 UNEF A Thread and a 5/8-24NEF V Thread. The receptacle has a B dimension of 9.53, a K dimension ranging from 1.58 to 3.96, an L dimension of 42.87, an M dimension of 14.28, an R dimension of 20.62, an S dimension of 27.79, and a T dimension of 3.05. This component is part of the MS3100 Class A series.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
