MS3100A 14 Wall mounting receptacle
Hunan Kaida Space Connectors
A wall mounting receptacle with 7/8-20 UNEF A Thread and 3/4-20 UNEF V Thread.
Technical specifications
- A Thread
- 7/8-20 UNEF
- B (Min)
- 15.88
- K Min /Max
- 1.58/3.96
- L Max
- 52.37
- M+0.79/-0.00
- 19.05
- R±0.12
- 23.01
- S±0.79
- 30.18
- T+0.25/-0.12
- 3.05
- V Thread
- 3/4-20 UNEF
About
The MS3100A 14 is a wall mounting receptacle designed for electrical connections. It features a 7/8-20 UNEF A Thread and a 3/4-20 UNEF V Thread. The receptacle has a B dimension of 15.88, a K dimension ranging from 1.58 to 3.96, an L dimension of 52.37, an M dimension of 19.05, an R dimension of 23.01, an S dimension of 30.18, and a T dimension of 3.05. This component is part of the MS3100 Class A series.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
