Noise Sources
Mercury Systems
High-performance noise sources ideal for receiver built-in test (BIT), bit error rate (BER) testing, and dithering circuits, available in coaxial and surface mount form factors.
Technical specifications
- RF Frequency
- 10 MHz to 18 GHz
- Noise Output
- 25 dB Min ENR
- Noise Spectral Density
- -149 dBm/Hz
- Peak Factor
- 5:01
- Bias Voltage
- 28 V
- Supply Current
- 25 mA Max
- Impedance
- 50 ohms
- Construction
- Coaxial
- Connector
- Type SMA(F)
- Operating Temperature
- -55 to 95 °C
- Storage Temperature
- -65 to 125 °
About
Mercury Systems has a long history of designing and manufacturing high-performance noise sources. These specialized products are ideal for applications such as receiver built-in test (BIT), bit error rate (BER) testing, and dithering circuits. Additionally, these products are available in a range of form factors including coaxial and surface mount. The product line includes Broadband Coaxial Noise Sources, Fullband Coaxial Noise Sources, High-Power Noise Sources, and Surface Mount Noise Sources, each with various models offering different frequency ranges, output power, spectral density, and bias voltages. Mercury also offers custom microwave solutions, allowing for configurable components and integrated RF solutions tailored to specific application requirements.
Documentation
- nst18-a-noise.pdf PDF source: www.mrcy.com ↗
- nma2218-a1t-noise.pdf PDF source: www.mrcy.com ↗
- ns5102-a1w-noise.pdf PDF source: www.mrcy.com ↗
Need the full ICD, test reports or a specific revision? Ask the supplier directly.
