CUBESAT THRUSTER
Perigee Aerospace
The CubeSat Thruster is a compact and capable cold gas propulsion system designed for CubeSats, offering excellent storage density, low leakage, and safe handling with refrigerant-based propellants.
Typed specifications10 values
Discloses 5 of 10 fields engineers filter by in this category (category median 3).
- Mass
- 1.17 kg product page 3.36 kg
- Thrust
- 200 mN product page 450 mN
- Specific impulse
- 41 s product page 41 s
- Total impulse
- 250 N·s product page 800 N·s
- Propellant
- R236fa product page R236fa
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier22 lines, in the manufacturer's own wording
- Parameters
- 0.8U
- Parameters (2)
- 2U
- Propellant
- R236fa
- Propellant (2)
- R236fa
- Thrust, maximum
- 200 mN
- Thrust, maximum (2)
- 450 mN
- Specific impulse, vac
- 41 s
- Specific impulse, vac (2)
- 41 s
- Mass, fully loaded
- 1.17 kg
- Mass, fully loaded (2)
- 3.36 kg
- - Empty
- 0.55
- - Empty (2)
- 1.21
- - Propellant
- 0.62
- - Propellant (2)
- 2.15
- Total impulse
- 250. N-s
- Total impulse (2)
- 800. N-s
- Âv for 10 kg bus
- 25 m/s
- Âv for 10 kg bus (2)
- 90. m/s
- - @ 298 k
- <5 W
- - @ 298 k (2)
- <5 W
- - @ 273 k (initial heating)
- <8 W
- - @ 273 k (initial heating) (2)
- <15 W
About
The CubeSat Thruster is a compact and capable cold gas propulsion system (CPS) designed for CubeSats. It utilizes refrigerant-based propellants (R236fa), offering excellent storage density, low leakage, and safe handling. The system is an all-in-one solution, integrating all electronics, the thruster nozzle, valves, and heaters within the tank, minimizing space requirements on the bus. It requires only power and command signals from the CubeSat. The system is designed for low power consumption, consuming less than 15 W during initial heating (at 273 K) and under 5 W during operation (at 298 K), thanks to thermal insulation and low-radiation surface treatments. It is available in two configurations, 0.8U and 2U, providing different thrust levels, total impulse, and delta-v capabilities for 10 kg buses.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
