Earth Horizon Sensor
Pyxis Space
The Pyxis Space Earth Horizon Sensor provides nadir-vector measurement for CubeSat attitude control using both visible (VIS) and infrared (IR) spectral observation. Detecting the Earth’s limb in two spectral bands improves robustness compared to single-band sensors, allowing reliable operation across different lighting conditions including eclipse transitions. The sensor achieves Earth pointing accuracy of 1° and […]
Typed specifications18 values
Discloses 4 of 8 fields engineers filter by in this category (category median 4).
- Accuracy
- 1 ° rms · datasheet p.2
- Mass
- 42 g datasheet p.2
- Envelope (L×W×H)
- 28 x 28 x 53 mm3 datasheet p.2
- Update rate
- 1 Hz datasheet p.2
- Field of view
- 80 ° HxV IR · datasheet p.2 92 ° HxV VIS | 120 ° HxV IR | 114 ° HxV VIS
- Supply voltage
- 4.5 V min · datasheet p.2 12 V max
- Power consumption
- 0.2 W datasheet p.2
- Data interface
- CAN 2.0B · datasheet p.2 I2C option | UART option
- Operating temperature
- -20 °C min · datasheet p.2 50 °C max
- Radiation tolerance (TID)
- 10 krad datasheet p.2
- Sensor class
- digital two-axis datasheet p.0
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier14 lines, in the manufacturer's own wording
- Dimensions
- 28 × 28 × 53 mm³
- Mass
- 32 g
- Observation bands
- Visible (VIS) and Infrared (IR)
- Pointing accuracy
- 1° Earth pointing
- Price
- €6,000
- Accuracy
- 1°
- Slew Rate
- up to 2 °/s
- Field of view
- 80° x 120° IR
- Field of view (2)
- 92° x 114° VIS
- Interface
- CAN 2.0B
- Supply voltage
- +4.5 V to +12 V
- Power
- 200 mW
- Operating temperature
- -20 °C to +50 °C
- Radiation
- 10 kRad
About
The Pyxis Space Earth Horizon Sensor provides nadir-vector measurement for CubeSat attitude control using both visible (VIS) and infrared (IR) spectral observation. Detecting the Earth’s limb in two spectral bands improves robustness compared to single-band sensors, allowing reliable operation across different lighting conditions including eclipse transitions. The sensor achieves Earth pointing accuracy of 1° and is housed in a 28 × 28 × 53 mm³ package weighing just 32 g — suitable for any CubeSat platform from 1U upward. It provides a cost-effective means of nadir stabilization for Earth observation, remote sensing, and communication missions where a constant Earth-pointing orientation is required. As part of the Pyxis Space ADCS product ecosystem, it interfaces seamlessly with the Pyxis Reaction Wheel, Sun Sensor, and Star Sensor systems for a complete attitude control solution. Priced at €6,000.
Documentation
Need the full ICD, test reports or a specific revision? Ask the supplier directly.
