Ka-Band Beam-Forming Integrated Circuits
Thorium Space Technology
A family of four Ka-band beam-forming ICs (Wildside2731, Mystic1721, Farside1721, Meadow2731) for satellite terminal and space payload applications, developed with Sivers Semiconductors.
Technical specifications
- Wildside2731 function
- TX (terrestrial)
- Wildside2731 frequency
- 27.5–31 GHz
- Wildside2731 TRL
- V
- Mystic1721 function
- RX (terrestrial)
- Mystic1721 frequency
- 17.7–21.2 GHz
- Mystic1721 TRL
- V
- Farside1721 function
- TX (space)
- Farside1721 frequency
- 17.7–21.2 GHz
- Farside1721 TRL
- IV
- Meadow2731 function
- RX (space)
- Meadow2731 frequency
- 27.5–31 GHz
- Meadow2731 TRL
- IV
- Independent beams per IC
- 2
- Antenna ports per beam
- 8
- Fabrication
- GlobalFoundries (via Sivers Semiconductors)
- Exclusive production rights until
- 2034
- Production readiness target
- Q3 2027
- Prototype characterization target
- Q2/Q3 2026
About
Thorium Space commissioned Sivers Semiconductors (Sweden) to design and manufacture a family of four Ka-band beam-forming integrated circuits for both terrestrial satellite terminals and space segment applications. Each IC incorporates dual parallel signal distribution networks, enabling simultaneous generation of two independent electromagnetic beams with eight antenna ports each — providing significant flexibility for multi-satellite access and interference mitigation.
The terrestrial pair — Wildside2731 (TX, 27.5–31 GHz) and Mystic1721 (RX, 17.7–21.2 GHz) — has reached TRL V. These ICs target ground-based flat-panel satellite communication terminals. The space-grade pair — Farside1721 (TX, 17.7–21.2 GHz) and Meadow2731 (RX, 27.5–31 GHz) — are at TRL IV and are designed for hybrid beam-forming in satellite payloads. All four ICs are claimed to represent the highest integration density currently available in this frequency range.
Each device integrates amplifiers, phase shifters, and frequency conversion circuits. Fabrication is performed at GlobalFoundries via Sivers Semiconductors, with Thorium Space holding exclusive production rights through 2034. Full prototype characterization is expected in Q2/Q3 2026, with production readiness targeted for Q3 2027.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
