LEOS-100 Satellite Platform
azista-bst-aerospace
150kg-class satellite bus with body-mounted panels for high-precision instruments — 50cm GSD Earth observation, 2kW power, 5-year design life.
Technical specifications
- Core volume
- 600 x 600 x 200 mm
- Mass
- 150 kg
- Design life
- 5 years (LEO)
- Payload mass
- 50-75 kg
- Power
- 2 kW mission support
- Earth observation resolution
- 50 cm GSD
- X-Band downlink
- 1 Gbps
- Propulsion
- Electrical
About
The LEOS-100 platform is a larger satellite bus supporting missions with up to 2 kW power requirements. It supports high-precision earth observation instruments at 50 cm ground sample distance and uses body-mounted solar panels. Bus communications include S-band TT&C and X-band downlink, fully encrypted, with electrical propulsion, designed for 5-year LEO missions.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
