CatSat 10 GHz Patch Antenna
FreeFall Aerospace
X-band patch antenna flown on NASA's CatSat CubeSat mission as the backup downlink solution.
Typed specifications2 values
Discloses 1 of 10 fields engineers filter by in this category (category median 3).
- Antenna type
- patch product page
- Flight heritage
- Operational on CatSat since July 2024 product page
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier4 lines, in the manufacturer's own wording
- Frequency
- 10 GHz (X-band); C-band beacon variant also flown
- Type
- Patch antenna
- Application
- Backup downlink on CatSat 6U CubeSat (NASA CSLI)
- Flight heritage
- Operational on CatSat since July 2024
About
FreeFall Aerospace’s X-band patch antenna flew on CatSat, a NASA CubeSat Launch Initiative 6U mission launched on July 4, 2024 in partnership with the University of Arizona. The 10 GHz patch antenna serves as the backup high-rate downlink for the spacecraft, complementing FreeFall’s inflatable X-band spherical high-gain antenna (the mission’s primary technology demonstration); a companion C-band patch variant acts as a radio beacon receivable by amateur radio operators worldwide. The compact, low-mass patch design suits small spacecraft where volume and power are at a premium, and demonstrates FreeFall’s portfolio of novel antenna systems for high-gain communications with minimum mass, power, complexity and cost.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
