GAUSS Mini Ground Dongle
GAUSS Srl
USB low-power UHF transceiver/TNC dongle for safely simulating a ground station under laboratory conditions.
Typed specifications7 values
Discloses 3 of 13 fields engineers filter by in this category (category median 2).
- Frequency bands
- UHF for TT&C · datasheet p.1
- Data rate
- 250 kbps with 4GFSK · datasheet p.1 0.3 kbps min | 100 kbps max
- EIRP
- -15 dBW max · datasheet p.1
- Data interface
- USB datasheet p.1
- Connector
- SMA connector for antenna datasheet p.1
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier15 lines, in the manufacturer's own wording
- Output power
- Up to 15 dBm
- Frequency band
- UHF for TT&C
- Interface
- USB, with drivers for Windows, Linux and MAC
- Protocol
- AX.25 supported
- Fec
- Viterbi k4 (Viterbi k7 & Reed-Solomon on request)
- Tnc
- Integrated TNC, KISS interface
- Mode
- Transparent mode supported
- Data rate
- 300 bps to 100 kbps (up to 250 kbps with 4GFSK on request)
- Sensitivity
- -122 dBm @1.2 kbps, -119 dBm @9.6 kbps, -109 dBm @50 kbps
- Gpio
- For external output amplifier exciter
- Firmware
- Upgradable from PC
- Modulations
- FSK/MSK/GFSK/GMSK
- Components grade
- Off the shelf industrial / automotive
- Compatibility
- Full compatibility with all GAUSS Radios
- Connector
- SMA connector for antenna
About
GAUSS Mini Ground Dongle is a USB low-power board to simulate a ground station safely under laboratory conditions. The USB dongle integrates both a low-power UHF transceiver and a TNC, miniaturizing common ground station rack systems. It was designed to give easy access to TT&C testing during final verifications and pre-integration periods, but it can also be used on an actual ground station if an external power amplifier is added. It is fully compatible with the GAUSS UHF Radio. The dongle comes with multi-platform software, so it can be used with any PC/Mac available in the lab. A special bundle includes both the Radio and the Mini Ground Dongle for quick system deployment.
Documentation
Need the full ICD, test reports or a specific revision? Ask the supplier directly.
