TDEMI Ultimate EMC/EMI Receiver
GAUSS Instruments
Top-of-the-line FFT-based real-time EMC/EMI measurement receiver up to 44 GHz — 128,000x faster than conventional receivers, CISPR 16-1-1 compliant.
Technical specifications
- Frequency range
- DC up to 44 GHz
- Real-time bandwidth
- 345 MHz standard (685/1000 MHz optional)
- Speed
- 128,000x faster than conventional receivers
- Compliance
- CISPR 16-1-1, ANSI C63.2
- Interface
- 10.1" touchscreen
- Models
- TDEMI Ultimate 6/9/18/26/30/40/44 (by GHz ceiling)
About
The TDEMI Ultimate is GAUSS Instruments’ flagship real-time FFT-based EMC receiver, offering a standard 345 MHz gapless quasi-peak real-time bandwidth (upgradable to 685 MHz or 1000 MHz). It performs real-time scanning across several GHz with simultaneous peak and average detection, fully compliant with CISPR 16-1-1 even at 0 dB attenuation. Available in frequency variants from DC/9 kHz up to 44 GHz.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
