Antenna-Integrated Terminal TQZD-10
Guodian Gaoke (Tianqi Satellite)
Compact all-in-one Tianqi satellite IoT terminal with integrated antenna, IP67, magnet mount.
Key figurescomparable across the catalogue
- Mass
- 0.2 kg
- Power
- 4.8 W
- Largest dimension
- 80 mm
- Design life
- 5 years
Normalised to common units so this product can be compared with others in its category. The supplier's own wording is below.
As published by the supplier
- Message size
- Max 120 bytes per message
- Frequency band
- UHF
- TX power
- ≥30 dBm
- RX sensitivity
- -125 dBm
- GNSS bands
- GPS L1 1575.42 MHz; BDS B1 1561.098 MHz
- Supply voltage
- 8~38 V
- TX current (12V)
- ≤400 mA
- Sleep current (12V)
- ≤1.5 mA
- TX power consumption
- ≤4.8 W
- Standby power
- ≤0.04 W
- Operating temperature
- -30°C ~ +80°C
- RS485 baud rate
- 115200 bps
- Connector
- M12 waterproof
- IP rating
- IP67
- Dimensions
- φ80×21 mm (diameter × height)
- Mass
- ≤200 g
- Service life
- >5 years
About
The TQZD-10 is a compact all-in-one Tianqi satellite IoT communication terminal with built-in satellite and GNSS antennas, sealed in an epoxy-resin-filled IP67 housing. It is designed for IoT data acquisition in areas without cellular coverage and for mobile asset tracking applications.
The terminal supports one RS485 interface for autonomous sensor data acquisition or as a satellite modem for a host system. Features include automatic satellite orbit calculation, ultra-low-power management, 6-axis attitude sensor, and internal temperature sensor. Strong built-in magnet (plus screw holes) enables mounting on vehicles, containers, and structures without tools. Wide input voltage, tiny form factor (80 mm diameter disc), and 200g weight make it ideal for mobile deployments.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
