Emergency Distress Terminal
Guodian Gaoke (Tianqi Satellite)
An emergency distress terminal with dual Tianqi satellite communication and AIS maritime communication capabilities, featuring Beidou and GPS dual-mode positioning for enhanced rescue reliability.
Typed specifications3 values
Discloses 2 of 10 fields engineers filter by in this category (category median 3).
- Mass
- 200 g product page
- Envelope (L×W×H)
- 125*50*30 mm product page
- TX RF output power
- 1 W min · product page
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier20 lines, in the manufacturer's own wording
- Tianqi communication message communication
- Supports sending Tianqi messages containing time and location information
- Tianqi communication operating frequency band
- UHF
- Tianqi communication transmit power
- ≥30 dBm
- Ais operating frequency
- 161.975 MHz、162.025 MHz
- Ais message communication
- Supports sending AIS standard messages containing time and location information
- Ais communication range
- >4 nautical miles
- Positioning receiving frequency band
- L1,1575.42 MHz;B1,1561.098 MHz
- Horizontal positioning accuracy
- Autonomous positioning <2.5CEP
- Positioning receiving sensitivity
- Acquisition: -147 dBm; Tracking: -162 dBm; Reacquisition: -168 dBm
- Positioning start-up time
- Cold start time <60s; Warm start time ≤15s; Hot start time ≤10s
- Tianqi communication antenna
- Tape measure antenna
- Positioning antenna
- Built-in ceramic antenna
- Power supply
- 6 V/1400 mAh disposable lithium-manganese battery pack
- Operating time
- 72h
- Power consumption
- Transmit power consumption ≤4 W; Static power consumption ≤0.4 W; Standby power consumption ≤0.01 W
- Operating temperature
- 20℃~55℃
- Storage temperature
- -30°℃~70°℃
- Protection level
- IP67
- Device dimensions
- 125*50*30 mm
- Mass
- 200 g
About
The Emergency Distress Terminal is a robust device designed for critical situations, offering dual communication channels through the Tianqi satellite system and AIS maritime communication. It integrates Beidou and GPS dual-mode positioning for accurate location data. Key features include a dual-backup distress alarm system (Tianqi + AIS), one-button activation for sending Tianqi satellite distress messages, and automatic alarming upon water immersion (triggered by cap removal). The device is engineered for low power consumption, extended battery life, and portability. It can transmit distress information to up to three emergency contacts, significantly improving the reliability of rescue operations. Its compact size and lightweight design make it easy to carry, while its IP67 protection rating ensures durability in harsh environments. The terminal supports sending Tianqi messages containing time and location information, and AIS standard messages with similar data. It operates on UHF for Tianqi communication and specific frequencies for AIS, with high positioning accuracy and sensitivity.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
