SPECTRA-L40
Hemeria
The SPECTRA-L40 is a nanosatellite platform designed for low-data-rate telecommunication networks, optimized for constellations with efficient power generation across various orbits.
Key figurescomparable across the catalogue
- Payload capacity
- 20 kg
- Thrust
- 0 N
Normalised to common units so this product can be compared with others in its category. The supplier's own wording is below.
As published by the supplier
- Taille de la plateforme
- 220x230x500 mm
- Masse de la plateforme
- 20 kg
- Masse max. de la charge utile
- 20 kg
- Volume max. de la charge utile
- 220 × 230 × 400 mm + 7U internes
- Capacité énergétique de la batterie
- 216 Wh
- Puissance de la charge utile (EOL @ 600 km SSO) - 10h30
- 40 W (moy.)
- Puissance de la charge utile (EOL @ 600 km SSO) - 6h00-18h00
- 65 W (moy.)
- Puissance de la charge utile (EOL @ 600 km SSO) - pointe
- 200 W
- Interfaces de données et d'alimentation
- LVDS, LVTTL, RS 485/422, CAN, SpW Option : SPI, l2C Régulé : 5 V, Non régulé : 15-17V Option : 3,3 V - 12 V - 28 V Toutes les lignes protégées par LCLs
- Débit sur la liaison montante
- 64 kbps (S-band)
- Débit sur la liaison descendante
- 1 000 kbps (S-band) X-Band (option) - 230-310 Mbps
- Delta-v
- 80 m/s - 150 m/s (option)
- Poussée
- >300 µN
- Erreur de précision de position
- 4 m
- Erreur de précision du mouvement
- 3 cm/s
- Exactitude temporelle
- 100 ns
- Erreur de pointage de l’attitude
- 0,7° @3sigma 0,09° @3sigma (Option)
- Erreur de connaissance de l’attitude
- 0,7° @3sigma 0,085° @3sigma (Option)
- Stockage des données pour la charge utile
- 28 Go (de base) + 32 Go (option)
- Durée de vie de la mission
- 5 ans 8 ans (option)
- Modes de pointage scao
- Géocentrique / Soleil · Options : Cible / Inertiel / Polynôme / Depuis la charge utile
About
The HEMERIA SPECTRA-L40 is a nanosatellite platform specifically engineered for building low-data-rate telecommunication networks from space. These satellites are designed to deliver a very high level of performance over a lifespan of more than 5 years. With efficient energy production capabilities across different orbits, the SPECTRA-L40 platforms are optimized for constellation deployments. The platform supports a maximum payload mass of 20 kg and a maximum payload volume of 220 × 230 × 400 mm plus 7U internal space. It features a battery capacity of 216 Wh and can provide an average payload power of 40 W (10H30) or 65 W (6H00-18H00), with a peak power of 200W. Data and power interfaces include LVDS, LVTTL, RS 485/422, CAN, SpW (Option: SPI, I2C), with regulated 5V and unregulated 15-17V, and optional 3.3V, 12V, 28V, all lines protected by LCLs. Communication capabilities include an S-band uplink of 64 kbps and an S-band downlink of 1,000 kbps, with an X-Band option offering 230-310 Mbps. The platform offers a Delta-V of 80 m/s (150 m/s option) and a thrust greater than 300 µN. Attitude determination and control features include a position accuracy error of 4 m, movement accuracy error of 3 cm/s, temporal accuracy of 100 ns, attitude pointing error of 0.7° @3sigma (0.09° @3sigma option), and attitude knowledge error of 0.7° @3sigma (0.085° @3sigma option). Data storage for the payload is 28 GB (basic) with an optional 32 GB. The mission life is 5 years, with an 8-year option. SCAO pointing modes include Geocentric and Sun, with options for Target, Inertial, Polynomial, and Payload-derived pointing.
