E14-150 14V SmallSat Electric Power System
ibeos
150W radiation-tolerant 14V SmallSat EPS with peak-power tracking, 96% solar array efficiency, 3.3V/5V/12V regulated buses, 10x switched outputs, I2C/SPI telemetry, 30 kRad TID, TRL 9.
Typed specifications54 values
Discloses 11 of 14 fields engineers filter by in this category (category median 7).
- Mass
- 140 g datasheet p.1
- Total output power
- 150 W maximum input · datasheet p.1 150 W max
- Conversion efficiency
- 96 % S/A conversion efficiency, typical at >50% load · datasheet p.1 95 % 12V output conversion efficiency | 92 % 3.3V output conversion efficiency | 93 % 5V output conversion efficiency
- Envelope (L×W×H)
- 96 x 90 x 14.5 mm datasheet p.1
- Outputs (as printed)
- 5.0-Volt regulated bus (6 A); 3.3-Volt regulated bus (3A); 12.0-Volt regulated bus (4A); Unregulated battery bus (10 A); 10x switched outputs datasheet p.1 3.3-Volt regulated bus (3A) | 12.0-Volt regulated bus (4A) | Unregulated battery bus (10 A) | 10x switched outputs
- Supply voltage
- 16.8 V product page 18 V min · input power | 42 V max · input power
- Power consumption
- 1.8 W Typical Quiescent Power Consumption · datasheet p.1 1.8 W typical quiescent, all converters enabled, no external loads
- Data interface
- I2C I2C @ 400 kbps · datasheet p.1 SPI SPI @ 1 Mbps | I2C
- Operating temperature
- -40 °C min · datasheet p.1 105 °C max
- Radiation tolerance (TID)
- 30 krad Si · datasheet p.1
- TRL
- 9 product page
- Unit type
- EPS without battery EPS card with battery charger, battery not integrated · datasheet p.1
- Board format
- 1U board 90x96 mm datasheet p.2
- Bus and outputs type
- hybrid (regulated rails + battery bus) regulated 3.3 V, 5 V, 12 V plus unregulated 14 V battery bus · datasheet p.1
- Unregulated (battery) bus voltage
- 14 V unregulated 14V battery bus · datasheet p.1 14 V unregulated battery
- Regulated output voltages
- 5 V regulated bus · datasheet p.1 3.3 V regulated bus | 12 V regulated bus
- Switchable outputs
- 10 10x switched outputs, 10 mOhm typical resistance · datasheet p.1
- Solar input voltage window
- 18–42 V maximum input power range · datasheet p.1
- Max solar input power
- 150 W max · >150-Watt maximum input power (18-42 V) · datasheet p.1
- Solar array regulation
- PPT (peak power tracking) solar array peak power tracking · datasheet p.1
- Protections
- battery over-charge / over-discharge datasheet p.1 over-voltage battery under/over-voltage protection | over-current (LCL) output latching current limiters; battery over-current | watchdog programmable spacecraft watchdog timer | over-current (LCL) +4
- Satellite class
- smallsat 100-500 kg SmallSat Electric Power System · datasheet p.1
- Max current per output
- 4 A 12.0-Volt regulated bus · datasheet p.1 3 A 3.3-Volt regulated bus | 6 A 5.0-Volt regulated bus | 10 A unregulated battery bus
- Battery voltage range accepted
- 16.8 V max · maximum charge voltage · datasheet p.1
- Max battery charge current
- 7 A max · maximum charge current · datasheet p.1
- MPPT
- yes datasheet p.1
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier16 lines, in the manufacturer's own wording
- Max solar array input
- >150W (18–42V input)
- S/a conversion efficiency
- 96%
- 3.3v output
- 3 A (92% efficiency)
- 5v output
- 6 A (93% efficiency)
- 12v output
- 4 A (95% efficiency)
- Unregulated 14v bus
- 10 A
- Max charge voltage
- 16.8 V
- Max charge current
- 7 A
- Switched outputs
- 10x (10 mOhm typical)
- Interfaces
- I2C @ 400 kbps; SPI @ 1 Mbps
- Quiescent power
- 1.8 W
- Dimensions
- 96 x 90 x 14.5 mm
- Mass
- 140 g
- Operating temperature
- -40 to +105 deg C
- TID
- 30 kRad(Si)
- TRL
- 9
About
The Ibeos E14-150 is a 150W SmallSat Electric Power System providing radiation-tolerant peak-power tracking solar array power conversion for 14V battery systems. Delivers regulated 3.3V (3A), 5V (6A), and 12V (4A) buses plus an unregulated 14V battery bus at 10A. Includes 10 switched power outputs with 10 mΩ typical on-resistance. Commands and telemetry via I2C at 400 kbps and SPI at 1 Mbps. Protection includes OVP, UVP, OCP, and a configurable watchdog timer with two-fault tolerant separation inhibits. Solar array conversion efficiency is 96%; regulator efficiencies are 93–95%. Operates from -40 to +105 deg C.
