HANBIT-Micro Launch Vehicle
INNOSPACE
Two-stage + kick stage small satellite launcher delivering up to 170 kg to 500 km SSO, with dual methane upper-stage engines and a precision kick stage.
Key figurescomparable across the catalogue
- Payload capacity
- 170 kg
Normalised to common units so this product can be compared with others in its category. The supplier's own wording is below.
As published by the supplier
- Payload capacity
- 170 kg (500 km SSO)
- Height
- 22.5 m
- Diameter
- 1.4 m
- Target orbit
- 500 km SSO
- Stage 1 engine
- 1× 245 kN hybrid (paraffin/LOx), 130 sec burn
- Stage 2 engines
- 2× 29 kN methane/LOx, 250 sec burn, Isp 350 sec
- Kick stage engine
- 1× 4 kN methane/LOx, 390 sec burn, Isp 350 sec
About
HANBIT-Micro is INNOSPACE’s mid-class small satellite launcher, designed to carry up to 170 kg to a 500 km SSO. The vehicle is a two-stage-plus-kick-stage configuration, 22.5 m tall with a 1.4 m diameter first stage.
The first stage uses a single 25-ton-class (245 kN) hybrid engine. The second stage uses two 3-ton-class methane/LOX engines (29 kN each), each with a 250-second burn time and 350 s specific impulse. Above the second stage, a dedicated kick stage with a 4 kN methane/LOX engine precisely inserts the satellite into the customer’s target orbit, burning for up to 390 seconds with a 350 s specific impulse. The kick stage enables precise orbital insertion to the customer-specified inclination and altitude.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
