TRIUMPH-LS Plus Land Survey System
JAVAD GNSS
All-in-one land-survey GNSS system with 4-engine RTK and patented RTPK post-processing — receiver, antenna, radio modem, and controller integrated into one field-ready unit.
Technical specifications
- Channels
- 874 (TRIUMPH-3 ASIC)
- Cellular
- 4G/LTE (Americas/EMEA)
- UHF
- 406-470MHz Rx / 902-928MHz spread-spectrum Rx/Tx
- RTK engines
- 4 parallel
- Power draw
- ~55% of prior generation
- Warranty
- 3 years, lifetime firmware/software updates
About
TRIUMPH-LS Plus integrates receiver, antenna, UHF/cellular modem, controller, and pole into one field-ready unit, powered by the TRIUMPH-3 ASIC. Its 4 Super-Engine RTK runs four parallel RTK engines under different parameter sets for cross-verified fixes, and patented RTPK combines RTK and PPK for real-time post-processing verification. It includes a 4G/LTE modem and UHF transmit/receive, integrating with JAVAD’s DPOS online post-processing service.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
