Sun Sensor
Pyxis Space
The Pyxis Space Sun Sensor is an ultra-compact, lightweight attitude sensor that provides coarse Sun direction measurement for CubeSat and nanosatellite platforms. At just 7 × 18 × 24 mm³ and 12 g, it is among the smallest space-grade sun sensors available and can be mounted on satellite body panels or structures with minimal volume […]
Typed specifications3 values
Discloses 2 of 8 fields engineers filter by in this category (category median 4).
- Mass
- 12 g product page
- Envelope (L×W×H)
- 7 × 18 × 24 mm³ product page
- Field of view
- 92 ° product page
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier6 lines, in the manufacturer's own wording
- Dimensions
- 7 × 18 × 24 mm³
- Mass
- 12 g
- Field of view
- 92° × 92°
- Pointing accuracy
- <0.2° (calibrated)
- Interface
- CAN 2.0B, I2C, UART
- Price
- €2,500
About
The Pyxis Space Sun Sensor is an ultra-compact, lightweight attitude sensor that provides coarse Sun direction measurement for CubeSat and nanosatellite platforms. At just 7 × 18 × 24 mm³ and 12 g, it is among the smallest space-grade sun sensors available and can be mounted on satellite body panels or structures with minimal volume penalty. It delivers a wide 92° × 92° field of view, enabling reliable Sun detection through most operational orientations, with calibrated accuracy better than 0.2°. The sensor outputs Sun angle data through standard CAN 2.0B or I2C interfaces, and also supports UART, allowing direct integration with most on-board computers and ADCS microcontrollers. In a typical CubeSat ADCS, multiple Pyxis Sun Sensors are mounted on different faces to provide full-sphere Sun coverage during detumbling and coarse attitude determination phases, prior to handoff to the star sensor for fine pointing. Priced at €2,500, it is the most affordable entry point in the Pyxis Space ADCS product line.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
