GRASP
TICRA
Dedicated software for fast and accurate design and analysis of advanced reflector antenna systems.
Technical specifications
- Feature
- Wizard for easy definition of single and dual reflector geometries
- Feature (2)
- Near-field and far-field calculations of vector fields
- Feature (3)
- Component library for common geometries: conic surfaces, general quadrics, radomes, panels, rectangular and circular struts
- Feature (4)
- Import of general reflector shapes from data files
- Feature (5)
- Component library of mathematical feed models and import of general feed definitions from file
- Feature (6)
- Import of general feed definitions from file and expansion in spherical modes
- Feature (7)
- Easy definition and fast analysis of quasi-optical networks
- Feature (transmit)
- Fast and easy computation of power transmitted between two antennas
- Feature (9)
- Advanced GTD algorithm for large reflector and scattering problems
- Feature (10)
- BoR-MoM for full-wave analysis of rotationally symmetric reflectors and lenses
- Feature (11)
- Design tool for quasi-optical networks
- Benefit
- Seamless integration with other products in TICRA Tools
- Benefit (2)
- Accurate analysis of reflectors with reliable results
- Benefit (3)
- Easy to import feed data from other software vendors or test ranges
- Benefit (4)
- Quick setup of complicated geometries
About
GRASP is TICRA’s dedicated software for reflector antenna systems, enabling fast and accurate analysis and design of the most advanced reflector antenna configurations. Multiple antennas may be defined within the same project, and the general command structure lets the user select which will be considered during a given analysis, enabling advanced scattering analysis of clusters of antennas. GRASP offers an advanced Physical Optics (PO) algorithm as the baseline analysis method, supplemented by optional GTD and Moment Method solvers for advanced applications. It is fully integrated in the TICRA Tools software framework, giving access to other TICRA analysis tools such as CHAMP 3D and POS within the same interface.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
