The 30kN Hybrid Engine is a rocket engine developed by Nammo Raufoss AS, designed for space propulsion applications.
30kN Hybrid Engine
The 30kN Hybrid Engine is a rocket engine developed by Nammo Raufoss AS, designed for space propulsion applications.
Description
The 30kN Hybrid Engine is a propulsion system developed by Nammo Raufoss AS. While specific details regarding its purpose, how it works, features, configurations, and flight heritage are not provided on this product page, its classification as a 'Hybrid Engine' and its placement within the 'Space Propulsion Thrusters and Engines' category on the manufacturer's website indicate its intended use in space applications. The engine is capable of producing 30 kilonewtons of thrust.
Specifications
| Thrust | 30,000 N in vacuum |
|---|---|
| Thrust Duration | 40 seconds |
| Engine Mass | 165 kg |
| Propellant Combination | 87.5% H2O2, and HTPB |
| Specific Impulse | 270 seconds, in vacuum |
| Total Impulse | >1000 kNs |
| Dimensions | 356 mm Diameter, 1.7 m Length |
| Materials | Stainless Steel construction |
| Fluidic Interface | 2 inch Tubing for Oxidiser feed |
| Technology Readiness Level | TRL8 |
