1U Cube Structure
Gran Systems
The 1U Cube Structure is a lightweight aluminum frame designed for CubeSat missions, providing a robust housing for internal components.
Typed specifications3 values
Discloses 1 of 11 fields engineers filter by in this category (category median 1).
- Mass
- 118 g product page
- Material (as printed)
- Aluminum T6 6061 product page
- Envelope (L×W×H)
- Length 100 x Width 100 x Height 113.5 mm product page
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier7 lines, in the manufacturer's own wording
- Temperature
- -50°C to +120°C
- Dimensions
- Length 100 x Width 100 x Height 113.5 mm
- Max. pc105 PCB size
- 95.9 x 95.9 mm
- Average weight
- 118 g
- Material
- Aluminum T6 6061
- Surface treatment
- anodized
- Pc104 mounting holes patterns
- LibreCube Specification referring to PC104
About
The 1U Cube Structure is a meticulously engineered aluminum frame specifically designed for CubeSat applications. Constructed from Aluminum T6 6061 with an anodized surface treatment, it offers durability and environmental resilience, capable of operating in temperatures ranging from -50°C to +120°C. The structure has physical dimensions of 100mm length, 100mm width, and 113.5mm height, with an average weight of 118g. It is designed to accommodate PC105 PCBs up to 95.9 x 95.9 mm, featuring four PC104 mounting holes. The PC104 mounting hole patterns adhere to the LibreCube Specification, ensuring compatibility with a wide range of CubeSat components.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
