MM200
AAC Clyde Space
The MM200 is a magnetorquer designed for small satellites, providing precise attitude control and reaction wheel desaturation.
Typed specifications18 values
Discloses 8 of 11 fields engineers filter by in this category (category median 8).
- Mass
- 12 g flanged housing, ±1 g · datasheet p.2 10 g minimal housing, ±1 g
- Measurement range
- 800 µT printed as +800 μT · datasheet p.2
- Envelope (L×W×H)
- Flanged 33 x 20 x 11.3 mm; Minimal 20 x 20 x 11.3 mm datasheet p.2
- Resolution
- 0.05 nT product page
- Output data rate
- 500 Hz max · sampling rate, configurable · datasheet p.2
- Noise density
- 1.18 nT/√Hz total noise spectral density · datasheet p.2
- Supply voltage
- 3.3 V product page
- Power consumption
- 0.02 W max · product page
- Data interface
- I2C packet-based I2C compatible interface · datasheet p.1
- Operating temperature
- -40 °C product page
- Radiation tolerance (TID)
- 30 krad max · radiation tolerance up to 30 krad · datasheet p.2
- Export status
- ITAR-free ITAR free · datasheet p.1
- Output type
- digital packet-based I2C compatible interface · datasheet p.1
- Satellite class
- CubeSat datasheet p.1
- Intended use
- spacecraft attitude control autonomous satellite attitude control · datasheet p.1 science instrument scientific measurements
- Configuration
- integrated (sensor + electronics) all analog signal processing happens on the instrument · datasheet p.1
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier9 lines, in the manufacturer's own wording
- Axes
- 3
- Measurement range
- ±100 µT
- Resolution
- 0.05 nT
- Noise density
- <0.05 nT/√Hz
- Interface
- I2C
- Supply voltage
- 3.3 V
- Power consumption
- <20 mW
- Operating temperature
- -40°C to +85°C
- Mass
- ~10 g
About
The MM200 is a magnetorquer developed by AAC Hyperion, specifically designed for small satellites. It enables precise pointing and rapid desaturation of any reaction wheels within the satellite’s attitude determination and control system. Magnetorquers are essential components for maintaining and adjusting a satellite’s orientation in orbit by interacting with Earth’s magnetic field. This product is suitable for missions requiring accurate attitude control.
Documentation
Need the full ICD, test reports or a specific revision? Ask the supplier directly.
