The Array — Commercial Dish Array Network
Cascade Space
First commercial dish array built for modern space missions — digital beamforming combines multiple smaller dishes into a single dynamically-sized aperture.
Typed specifications24 values
Discloses 3 of 14 fields engineers filter by in this category (category median 2).
- Frequency bands
- S Deep configuration · description S Deep+ configuration | S Lunar configuration | S Mini configuration | X Deep configuration +3
- G/T
- 37.7 dB/K Deep configuration · description 42.6 dB/K Deep+ configuration | 28.6 dB/K Lunar configuration | 25.6 dB/K Mini configuration | 47.5 dB/K Deep configuration +3
- EIRP
- 91 dBW Deep configuration · description 101 dBW Deep+ configuration | 72.9 dBW Lunar configuration | 66.9 dBW Mini configuration | 101 dBW Deep configuration +3
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier5 lines, in the manufacturer's own wording
- Mini configuration
- S-band G/T 25.6 dB/K, EIRP 66.9 dBW; X-band G/T 35.4 dB/K, EIRP 76.9 dBW
- Lunar configuration
- S-band G/T 28.6 dB/K, EIRP 72.9 dBW; X-band G/T 38.4 dB/K, EIRP 82.9 dBW
- Deep configuration
- S-band G/T 37.7 dB/K, EIRP 91 dBW; X-band G/T 47.5 dB/K, EIRP 101 dBW
- Deep+ configuration
- S-band G/T 42.6 dB/K, EIRP 101 dBW; X-band G/T 52.4 dB/K, EIRP 111 dBW
- Scaling roadmap
- 1 dish to 200 dishes across multiple global locations
About
Cascade Space is building a network of dish arrays to replace reliance on the oversubscribed NASA Deep Space Network. Rather than single large dishes (expensive to build, high maintenance, fixed aperture size), Cascade uses arrays of smaller dishes that are cheaper to build, more reliable, and offer dynamically adjustable aperture size and pricing. Digital beamforming combines multiple dishes into a single aperture — as more dishes are added, the beam sharpens, focusing more power toward the spacecraft. The roadmap includes a Mini array (1 dish, S-Band Rx), scaling to 15 dishes with Lunar+/S&X Tx/Rx/Ranging, additional locations, and a Deep+ global coverage configuration of 200 dishes.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
