CONDOR Mk3.1
Mynaric
The CONDOR Mk3.1 is a versatile optical communication terminal designed for inter-satellite, space-air, and space-ground connectivity in various orbits, optimized for LEO constellations.
Typed specifications7 values
Discloses 2 of 13 fields engineers filter by in this category (category median 3).
- Envelope (L×W×H)
- 280 x 270 x 371 product page 205 x 170 x 157 | 230 x 190 x 128
- TX RF output power
- 4 W product page
- Data rate
- 313 000–2 500 000 kbps product page
- Supply voltage
- 22 V product page
- Power consumption
- 4 W product page
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier12 lines, in the manufacturer's own wording
- Link distance
- greater than 6,500 km
- Aperture diameter tx
- 85 mm
- Aperture diameter rx
- 90 mm
- Field of regard azimuth
- -175⁰ to +175⁰
- Field of regard elevation
- -55° to +85⁰
- Operational wavelength
- 1553.33/1536.61 nm band
- Optical tx power
- 4 W
- Data rates
- 0.313 to 2.5 Gbps
- Dimensions (lwh in mm) optical head
- 280 x 270 x 371
- Dimensions (lwh in mm) dual occ
- 205 x 170 x 157
- Dimensions (lwh in mm) quad occ
- 230 x 190 x 128
- Supply voltage
- 22 V - 38 V (DC)
About
The CONDOR Mk3.1 is an advanced optical communication terminal that enables intra-plane and cross-plane inter-satellite connectivity across various orbits, as well as Space-Space, Space-Air, or Space-Ground communication. It is an evolution of the successful CONDOR Mk3 and is compliant with SDA Tranche 1 standards. Designed with best-in-class concepts for LEO constellations, it offers significant Size, Weight, and Power (SWAP) advantages. Key features include full compliance with SDA OCT Standard v3.1, support for link distances greater than 10,000 km, and flexible data rates up to 2.5Gbps, with options for 10 Gbps (OOK) and 100 Gbps (DP-QPSK). The terminal provides secure data transmission and is highly resistant to jamming, spoofing, and electromagnetic interference (EMI) compared to RF systems. It operates in a license-free spectrum, requiring no ITU or FCC frequency coordination, and is designed for over 5 years of operation in LEO. Operational features include a hyper hemispherical Field of Regard (FoR) with fast acquisition time, a highly modularized design with an optimized Optical Head and a separate Optical Communication Controller (OCC). One OCC can control up to four Optical Heads, which reduces power consumption and mass for multiple Optical Head configurations per satellite. It supports seamless link configuration and interoperability with various third-party optical communication terminals, offering full duplex, symmetrical, simultaneous transmit and receive capabilities. The system is built to withstand high micro-vibration environments, extended temperature ranges, and radiation effects.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
