CAST 2000 Satellite Platform
Shenzhen Aerospace Dongfanghong Satellite
The CAST 2000 is a compact, high-performance, and flexible satellite platform featuring S-band TT&C, X-band data transmission, and 3-axis attitude stabilization.
Typed specifications2 values
Discloses 1 of 7 fields engineers filter by in this category (category median 3).
- Mass
- 200–400 kg product page
- Pointing accuracy
- 0.1 ° max · product page
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier9 lines, in the manufacturer's own wording
- Orbit type
- Low, Medium, High
- Service life span
- ≥ 3 years
- Attitude measurement accuracy
- ≤ 0.03° (3 sigma)
- Attitude control accuracy
- ≤ 0.1° (3 sigma)
- Attitude stability
- ≤ 0.001°/s (3 sigma)
- Solar array output power
- ≥ 1 KW (BOL) ≥ 900 W (EOL)
- Bus mass
- 200-400 kg
- Payload capability
- 300-600 kg
- Attitude control mode
- 3-axis Stabilisation, Sway Maneuver Capability
About
The CAST 2000 is a compact satellite platform known for its high performance, expandability, and flexibility. It is equipped with an S-band TT&C (Telemetry, Tracking, and Command) sub-system and an X-band data transmission sub-system. The platform features 3-axis attitude stabilization, enabling highly precise control, large-range sway maneuvers, and flexible orbit maneuvers. It also boasts highly integrated housekeeping and an effective power supply system. This platform has been successfully applied in several Chinese small satellites, including the OceanSat-1A, 1B, and Huanjing-A, B satellites, demonstrating excellent performance and reliability. Furthermore, the VRSS-1 remote sensing satellite, launched on September 29, 2012, was manufactured based on the CAST 2000 platform and delivered in orbit on September 2, 2013.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
