AF-M315E (ASCENT) Green Monopropellant
Digital Solid State Propulsion
HAN-based green liquid monopropellant, higher performance and lower toxicity than hydrazine, used in NASA GPIM.
Typed specifications1 values
Discloses 1 of 10 fields engineers filter by in this category (category median 3).
- Propellant
- AF-M315E (HAN) Safety Data Sheet of the propellant itself · datasheet p.1
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier11 lines, in the manufacturer's own wording
- Appearance
- Translucent, light pink-orange liquid
- Specific gravity
- 1.46
- Freezing point
- Does not freeze; glasses at -80°C
- Ph
- 3.7-4.0
- Viscosity
- 23 cP at 25°C
- Autoignition temperature
- 140°C (runaway onset for slow cook-off)
- Shock sensitivity
- 0 cards in NOL gap test; 'No Go' in SLSGT @ 70 kbar
- Electrostatic discharge sensitivity
- >1 J (10 of 10 negative tests)
- Hazard classification
- 1.4C
- Price - 10lb (1gal)
- $3,850
- Price - 50lb (5gal)
- $16,500
About
AF-M315E is a hydroxylammonium nitrate (HAN)-based ‘green’ liquid monopropellant developed by the Air Force Research Laboratories (AFRL) and licensed for production by Digital Solid State Propulsion (DSSP). Marketed under the ASCENT name, it provides higher performance and lower toxicity than hydrazine, the legacy storable monopropellant used in satellite and spacecraft propulsion. It ships as a 1.4C hazard class material. A current ATF permit and end user agreement are required by the customer for purchase. AF-M315E gained prominence as the propellant used in NASA’s Green Propellant Infusion Mission (GPIM). Applications include satellite thrusters, in-space propulsion, and reaction control systems requiring a non-toxic hydrazine alternative.
Documentation
Need the full ICD, test reports or a specific revision? Ask the supplier directly.
