GaN Ku SSPA/BUC 150W/325W/600W 1:1 REDUNDANCY SYSTEM – Indoor
TTI Norte
An indoor 1:1 redundancy system for Ku-band satellite communication, featuring GaN SSPA/BUC transmitters with selectable power outputs of 150W, 325W, or 600W.
Typed specifications3 values
Discloses 0 of 10 fields engineers filter by in this category (category median 2).
- Envelope (L×W×H)
- 19” product page 19” Rack 42 U (H) x 1 m (D)
- Power consumption
- 150 W product page
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier7 lines, in the manufacturer's own wording
- Configuration
- 1:1 Redundancy System
- Transmitter type
- GaN Ku SSPA/BUC
- Power output
- 150 W/325 W/600 W
- Installation environment
- Indoor
- Controller sub-rack height
- 2U
- Controller sub-rack size
- 19”
- System rack dimensions
- 19” Rack 42 U (H) x 1 m (D)
About
This is an indoor 1:1 redundancy system designed for Ku-band satellite communication, utilizing GaN high-power SSPA/BUC transmitters. The system includes two GaN SSPA/BUC units, a redundancy waveguide assembly outdoor kit, waveguide sections, a waveguide load, and a waveguide switch. It also features a redundancy system controller, which is a standard indoor unit housed in a 2U-high 19” sub-rack, equipped with Ethernet and USB local ports, and dual internal power supplies. The system comes with essential cabling, including AC cables and M&C cables. It also includes a breaker panel and is designed for rack mounting in a 19” rack (42U H x 1m D).
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
