HIGH POWER GaN DBS SSPA 1kW/2kW/3.5kW Outdoor/Indoor
TTI Norte
A high-power GaN DBS SSPA available in 1kW, 2kW, or 3.5kW output power, suitable for both outdoor and indoor installations, with a wide operating frequency range.
Typed specifications51 values
Discloses 5 of 10 fields engineers filter by in this category (category median 2).
- Frequency bands
- C TX · datasheet p.1
- Frequency range
- 5 850–6 425 MHz datasheet p.2 17 300–18 400 MHz operating frequency range (DBS)
- Envelope (L×W×H)
- 1370 x 1070 x 1000 mm product page 19" rack cabinet 44 U (H), 1 m (D); qty x1 (1 kW / 2 kW), qty x2 (3.5 kW) indoor | 1200 x 1200 x 1000 mm outdoor, 1 kW | 1200 x 1200 x 2000 mm outdoor, 2 kW | 1200 x 1600 x 2000 mm outdoor, 3.5 kW +1
- EIRP
- 31.2 dBW PSAT (typical) · datasheet p.2 29 dBW PLINEAR* | 30.8 dBW PLINEAR* | 31.8 dBW PSAT (typical) | 33.3 dBW PLINEAR* +3
- Supply voltage
- 90–264 V Input · datasheet p.2 90–264 V input voltage, 50-60 Hz
- Power consumption
- 5 000 W max · 1 kW model, power consumption @ PSAT (<5 kW) · datasheet p.2 10 000 W max · 2 kW model, power consumption @ PSAT (<10 kW) | 20 000 W max · 3.5 kW model, power consumption @ PSAT (<20 kW) | 4 600 W max · PSAT
- Data interface
- RS-485 M&C (ASCII commands) · datasheet p.1 Ethernet M&C indoor | Ethernet M&C outdoor | Ethernet optional Ethernet port (Telnet, HTTP web page, SNMP) | RS-485 Remote control +4
- Operating temperature
- 0–50 °C indoor · datasheet p.2 -40–55 °C option: extended temperature range | -30–55 °C outdoor
- Offering
- RF or baseband equipment GaN based SSPAs/BUCs for broadcast satcom · datasheet p.1
- Transmit power
- 1 000 W 1 kW model, PSAT typical (60 dBm) · datasheet p.2 794.33 W 1 kW model, linear output power PLINEAR | 501.19 W 1 kW STANDARD PC system, at Psat when one SSPA is in failure … | 1 148.15 W 2 kW HYPER PC system, at Psat when one SSPA is in failure (~2… | 1 584.89 W 2 kW model, linear output power PLINEAR +4
- VSWR
- 1.5 max · input VSWR ≤1.5:1 · datasheet p.2 1.3 max · output VSWR ≤1.3:1
- Amplifier gain
- 70 dB min · gain >70 dB · datasheet p.2
- Connector
- RF Input: N (f); RF Output: WR62 grooved; RF sample: SMA; M&C: Ethernet or 19-pin MIL circular (outdoor), Ethernet or 15-pin D-Sub (indoor) datasheet p.2
- Survival temperature
- -40–85 °C datasheet p.2 -40–85 °C storage temperature
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier27 lines, in the manufacturer's own wording
- Supply voltage
- 90-264 VAC, 50-60 Hz
- Power consumption @ psat 1 kw
- <5 kW
- Power consumption @ psat 2 kw
- <10 kW
- Power consumption @ psat 3.5 kw
- <20 kW
- Dimensions (l x w x h) outdoor 1 kw / 2 kw
- 1370 x 1070 x 1000 mm
- Dimensions (l x w x h) outdoor 3.5 kw
- 1370 x 2000 x 1000 mm
- Indoor rack cabinet
- 44 U (H), 1 m (D)
- Operating temperature outdoor
- -30 ºC to +55 ºC
- Operating temperature indoor
- 0 ºC to +50 ºC
- Storage temperature
- -40 ºC to +85 ºC
- Humidity outdoor
- 100 % condensing
- Operating frequency range
- 17.30 - 18.40 GHz
- Output power (psat (typical)) 1 kw
- 60 dBm
- Output power (psat (typical)) 2 kw
- 63 dBm
- Output power (psat (typical)) 3.5 kw
- 65.4 dBm
- Linear output power (plinear*) 1 kw
- 59 dBm
- Linear output power (plinear*) 2 kw
- 62 dBm
- Linear output power (plinear*) 3.5 kw
- 64.4 dBm
- Gain
- >70 dB
- Gain flatness over full band
- <4 dB p-p
- Gain flatness over any 40 mhz
- <1 dB p-p
- Gain variation over temperature
- <± 1.5 dB
- Attenuation adjustment range
- 30 dB in 0.25 dB step
- Input vswr
- ≤1.5:1
- Output vswr
- ≤1.3:1
- Spectral regrowth
- -25 dBc @ PLINEAR*
- Spurious
- -60 dBc max @ PLINEAR*
About
This is a high-power GaN DBS SSPA available in 1kW, 2kW, or 3.5kW output power, designed for both outdoor and indoor installations. It operates with an input voltage of 90-264 VAC, 50-60 Hz. Power consumption at PSAT is <5 kW for 1 kW, <10 kW for 2 kW, and 85 ºC), reflected power, and high input-output power. Electrical specifications include an operating frequency range of 17.30 – 18.40 GHz, output power (PSAT typical) of 60 dBm (1 kW), 63 dBm (2 kW), 65.4 dBm (3.5 kW), and linear output power (PLINEAR*) of 59 dBm (1 kW), 62 dBm (2 kW), 64.4 dBm (3.5 kW). Gain is >70 dB, gain flatness is <4 dB p-p over full band and <1 dB p-p over any 40 MHz, and gain variation over temperature is <± 1.5 dB. Attenuation adjustment range is 30 dB in 0.25 dB steps. Input VSWR is ≤1.5:1 and output VSWR is ≤1.3:1. Spectral regrowth is -25 dBc @ PLINEAR* and spurious is -60 dBc max @ PLINEAR*. Options include extended temperature range (-40 ºC, +55 ºC), receive reject filter (external), harmonic filter (external), L to DBS band up-converters in 1:1 redundancy configuration (external), SNMP, AC breaker box, Automatic Control Mode (AGC, ALC), and pressure window.
