VHF/UHF Antenna System 1
ISISPACE Group
Deployable VHF/UHF antenna system for 1U–3U CubeSats with up to 4 tape-spring antennas, redundant thermal knife deployment, and I2C interface.
Typed specifications8 values
Discloses 2 of 10 fields engineers filter by in this category (category median 3).
- Mass
- 90 g max · product page
- Frequency range
- 145 MHz product page
- Envelope (L×W×H)
- 98 x 98 x 7 mm (including aluminium cover plate) product page
- Power consumption
- 2 W product page 0.04 W max | 0.06 W max
- Operating temperature
- -20 °C product page -5 °C
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier15 lines, in the manufacturer's own wording
- Mass
- < 90 g
- Envelope stowed (L x W x H)
- 98 x 98 x 7 mm (including aluminium cover plate)
- Power consumption — nominal (3V3 model)
- < 40 mW
- Power consumption — nominal (5V model)
- < 60 mW
- Interfaces
- Electrical: Miniature 9-pin OMNETICS connector; Data: I2C
- Frequency range
- 145 MHz – 868 MHz
- Antenna return loss at resonance
- > 10 dB
- Operational temperature range
- -20°C to +60°C
- Deployment temperature range
- -5°C to +60°C
- Antenna main beam gain
- UHF: 0 dBi; VHF: 0 dBi
- Max RF power
- 2 W
- Bandwidth — UHF
- > 50 MHz (-10 dB bandwidth)
- Bandwidth — VHF
- > 10 MHz (-10 dB bandwidth)
- Antenna deployment duration
- < 5 s
- Antenna length
- 55 cm tape-spring per element
About
The ISISPACE VHF/UHF Antenna System for 1U–3U CubeSats features up to four 55 cm tape-spring antennas and a redundant thermal knife deployment system. It offers seamless compatibility with UHF/VHF radios. The top face can accommodate solar panels, patch antennas, and sensors, offering further adaptability for integration.
The antenna system supports frequencies from 145 MHz to 868 MHz, covering the full VHF-to-UHF range used in amateur and commercial CubeSat communications. With a stowed footprint of 98 x 98 x 7 mm and mass under 90 g, it is optimized for tight CubeSat volume budgets.
The system connects via a miniature 9-pin OMNETICS connector and communicates through I2C for deployment command and telemetry. Antenna elements deploy in under 5 seconds. The antenna is compatible with most commercial UHF/VHF radio transceivers and has been proven on numerous CubeSat missions.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
