Warlock
Magdrive
The Magdrive Warlock is a compact electric propulsion system for CubeSats, utilizing a metal propellant and pulsed power to generate high thrust.
Typed specifications26 values
Discloses 7 of 10 fields engineers filter by in this category (category median 3).
- Propulsion family
- electric datasheet p.2 electric pulsed plasma thruster
- Mass
- 3 kg nominal · datasheet p.2 3 kg full system | 3 kg max
- Thrust
- 100 mN nominal · datasheet p.2 40 000 mN | 4 000 mN ECO | 50 000 mN max | 10 000 mN SPORT +1
- Envelope (L×W×H)
- 20x10x10 nominal · datasheet p.2 20 x 10 x 10 cm + 'tunacan' | 20x10x10 max
- Specific impulse
- 1 500 s nominal · datasheet p.2 5 000 s | 4 500 s ECO | 1 500 s max | 1 800 s SPORT
- Total impulse
- 3 000 N·s min · nominal · datasheet p.2 50 000 N·s min · max
- Propellant
- metal fuel storable solid metal propellant · datasheet p.1
- Power consumption
- 0.2–150 W datasheet p.1
- Power at thrust
- 150 W ECO · datasheet p.2 150 W SPORT
- Thrust vector control
- other magnetic vectoring up to 10° (TBC) · datasheet p.1
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier10 lines, in the manufacturer's own wording
- Integrated system size
- 2U cubesat
- Dry mass (including propellant, onboard processor, energy storage, and plasma injector)
- 2.5 kg
- Thrust vectoring
- up to 10˚
- Power
- 2 – 100 W
- Thrust
- 0.1 – 10 N
- Specific impulse
- 1500 s
- Total Impulse
- >3 kN s
- Energy Storage
- 10 kJ
- Mass
- 3 kg
- Dimensions
- 20 x 10 x 10 cm
About
The Magdrive Warlock is an electric propulsion system that generates thrust an order of magnitude higher than other similar-sized electric propulsion systems. It uses a metal propellant and recharged internal energy to create a high-energy plasma. The full integrated system fits inside a single 2U CubeSat with a dry mass of 2.5 kg, including propellant, onboard processor, energy storage, and plasma injector. The thruster employs a pulsed power system (PPS) to deliver a multi-kA, MW class electrical current pulse to the plasma injector. It offers customizable performance, enabling adjustable specific impulse and deep throttling for rendezvous, proximity operations, and precise maneuvering. An integrated microprocessor allows it to be commanded through the satellite’s master controls, ensuring an easy-to-integrate propulsion system. The use of storable metal propellant removes the need for heavy fuel tanks, cryogenics, or pressurization, and eliminates handling hazards. Furthermore, the Warlock provides directional thrust, capable of vectoring up to 10 degrees for main propulsion or attitude control by altering its magnetic properties.
