PW LDMOS S SSPA 350W Indoor
TTI Norte
An indoor Pulsed Wave LDMOS SSPA with 350W output power, designed for industrial, scientific, and medical applications, featuring air cooling and standard 19” rack mounting.
Typed specifications6 values
Discloses 3 of 8 fields engineers filter by in this category (category median 2).
- Mass
- 11 000 g product page
- Frequency range
- 3 000 MHz product page
- Envelope (L×W×H)
- 483 x 88 x 322 mm / 19” Standard, 2U height product page
- TX RF output power
- 349.95 W product page
- Power consumption
- 1 200 W max · product page
- Operating temperature
- 10 °C product page
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier19 lines, in the manufacturer's own wording
- Supply voltage
- AC 100-264 VAC 50/60 Hz
- Power consumption @ psat
- <1200 W
- Dimensions (W x H x D)
- 483 x 88 x 322 mm / 19” Standard, 2U height
- Mass
- 11 kg
- Operating temperature
- 10 °C to 40 °C
- Storage temperature
- -40 ºC to +85 ºC
- Humidity
- 90 % non-condensing
- Input frequency range
- 3 GHz ±5 MHz
- Operating mode
- Pulsed wave
- Output power (p1 db (typical))
- 55.44 dBm
- Gain
- > 57 dB
- Gain flatness
- < 1 dB
- Input level (nominal)
- -2 dBm to 4 dBm
- Attenuation adjustment range
- 6 dB
- Input vswr
- <1.4:1
- Output vswr
- Full reflection all phases
- Pulse width
- 100 ms max.
- Duty cycle
- 10 % max.
- Rise/fall time
- <50 ns
About
This is an indoor Pulsed Wave (PW) LDMOS Solid State Power Amplifier (SSPA) providing 350W of output power, specifically designed for industrial, scientific, and medical (ISM) applications. It features highly efficient LDMOS technology for superior lifetime and high MTBF. The unit is air-cooled and designed for standard 19” rack mounting (2U height). It offers user-friendly LED indicators for local control and includes fault and alarm interfaces. Remote control is available via discrete analog/digital signals, monitoring parameters like output power, current, power supply, and temperature. It has internal self-protection against temperature, fan failure, overduty, and power supply failure. The SSPA operates with an input frequency range of 3 GHz ±5 MHz and provides a gain of >57 dB. It supports customizable input level and attenuation adjustment ranges.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
