Robust On-Board Data Handling Unit
S4 - Smart Small Satellite Systems GmbH
A radiation-tolerant On-Board Data Handling (OBDH) unit that uses software-based fault protection and commercial components, offering standard UNISEC bus interfaces for satellite integration.
Typed specifications11 values
Discloses 2 of 13 fields engineers filter by in this category (category median 5).
- Mass
- 20 g max · product page
- CPU clock
- 19 000 MHz product page
- Envelope (L×W×H)
- 20x20x20 mm product page
- Supply voltage
- 5 V product page 3.3–8.4 V
- Power consumption
- 0.4 W max · product page 1 W max
- Operating temperature
- -50–50 °C product page
- Design lifetime
- 5 years product page
- Survival temperature
- -60–100 °C product page
- Flight heritage
- More than 5 years without any interruption of service in polar LEO product page
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier17 lines, in the manufacturer's own wording
- Radiation protection approach
- Software-based, using advanced FDIR and redundancy
- Component type
- Commercial (COTS) chips
- Flight heritage
- More than 5 years without any interruption of service in polar LEO
- Bus interface
- Standard UNISEC bus electrical interfaces
- Momentum
- 2.0 mNms
- Nominal rotational speed
- 19,000 rpm
- Nominal torque
- 0.1 mNm
- Mass
- < 20 g
- Dimensions
- 20x20x20 mm
- Supply voltage
- 5 V
- Operating voltage
- 3.3-8.4 V
- Power consumption (nominal)
- < 400 mW
- Power consumption (peak)
- < 1000 mW
- Nom. ambient temperature
- 0 °C
- Operating temperature
- -50 to +50 °C
- Survival temperature
- -60 to +100 °C
- Lifetime
- 5 years
About
The Robust On-Board Data Handling Unit (OBDH) implements a new concept of radiation protection achieved through software rather than radiation-hardened hardware, relying on advanced FDIR (Fault Detection, Isolation and Recovery) and redundancy approaches. This approach has demonstrated very reliable performance in orbit. Despite using only commercial (COTS) chips rather than space-qualified radiation-hardened components, the unit is able to handle the radiation environment of polar LEO orbits, having operated for more than 5 years without any interruption of service. The OBDH is equipped with standard UNISEC bus electrical interfaces, enabling straightforward integration into satellite systems that follow the UNISEC bus standard. A product flyer is available for further technical details.
Documentation
Need the full ICD, test reports or a specific revision? Ask the supplier directly.
