GAMALINK
TEKEVER
GAMALINK is an advanced and flexible software-defined radio (SDR) optimized for in-orbit connectivity, supporting simultaneous ground and inter-satellite links with robust RF protocols and ranging capabilities.
Typed specifications28 values
Discloses 5 of 13 fields engineers filter by in this category (category median 5).
- Mass
- 910 g Deep Space · datasheet p.2 910 g Deep Space version | 450 g New Space | 450 g New Space version
- Frequency range
- 2 200–2 450 MHz datasheet p.2
- Envelope (L×W×H)
- 160 x 120 x 65 mm Deep Space · datasheet p.2 160 x 120 x 65 mm Deep Space version | 96 x 94 x 45 mm New Space | 96 x 94 x 45 mm New Space version
- TX RF output power
- 0.1 W product page 0.1 W min · RF output power 100mW to 4W | 4 W max · RF output power 100mW to 4W
- Data rate
- 10 kbps min · net data rate, adaptive · datasheet p.2 500 kbps max · net data rate, adaptive
- Supply voltage
- 22–32 V unregulated · datasheet p.2
- Power consumption
- 0.1 W product page
- Data interface
- RS-422 2 x (up to 460800 baud) · datasheet p.2 other 2 x PPS input | RS-422 2 x RS-422
- Radiation tolerance (TID)
- 20 krad datasheet p.2 20 krad qualified for TID up to 20krad; SEE/SEL tolerant
- Function
- SDR transceiver SDR-based Inter-Satellite Link · datasheet p.2
- Link use
- inter-satellite link datasheet p.2
- Frequency band
- S datasheet p.2
- Flight heritage
- ESA HERA MISSION datasheet p.3 ESA PROBA 3 MISSION
- Satellite class
- CubeSat New Space version compatible with the CubeSat form factor · datasheet p.2
- Data interface speed
- 0.461 Mbps max · RS-422 · datasheet p.2
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier14 lines, in the manufacturer's own wording
- Communications range
- 10 cm to 1000+ k
- Frequency band
- S-band (2.2 to 2.45 GHz)
- RF output power
- 100 mW to 4 W
- Net data rate
- 10 kbps to 500 kbps (adaptive)
- Supply voltage
- 22 V to 32 V unregulated
- Data interfaces
- 2 x RS-422 (up to 460800 baud) 2 x PPS input
- Ranging accuracy
- Better than 50 cm (3-sigma)
- Range rate accuracy
- Better than 1 mm/s with 60s of integration time
- Time correlation accuracy
- Better than 1 ms (at interface level)
- Radiation protection
- Qualified for TID up to 20krad SEE/SEL tolerant.
- Deep space dimensions
- 60 x 120 x 65 mm
- Deep space mass
- 910 g
- New space dimensions
- 96 x 94 x 45 mm
- New space mass
- 450 g
About
GAMALINK is one of the most advanced and flexible software-defined radios on the market, providing simultaneous support for multiple types of ground and inter-satellite links. It is characterized by high flexibility in frequency allocation, a robust RF protocol, ranging measurements, and correlation mechanisms embedded in the data communications and networking features, allowing for different topologies and data relaying. GAMALINK is a technology enabler for creating a unique communications network incorporating not only the space but also the ground segment. It is an RF communications platform optimized for in-orbit connectivity, supporting point-to-point and multi-node packet-oriented communications. It offers seamless ranging, range rate, and time correlation/synchronization capability together with data exchange, making it a perfect enabler for formation flying, swarm missions, or radio science applications.
GAMALINK is available in two different configurations: a Deep Space version with a robust mechanical housing providing additional radiation shielding, and a New Space version with a more compact and streamlined design, compatible with the CubeSat form factor.
TEKEVER is providing Inter-Satellite Link (ISL) technology for ESA’s Hera mission, supporting robust communications and relative positioning within the mission architecture. Hera launched in October 2024 and has since completed key early mission milestones, including a Mars flyby in March 2025, as it continues its journey to the Didymos system. TEKEVER’s ISL capability helps enable coordinated spacecraft operations and precise measurements, supporting Europe’s planetary defence objectives.
TEKEVER is involved in ESA’s Proba-3 mission, providing an Inter-Satellite Link critical subsystem based on GAMALINK technology to support precision formation flying. Proba-3 launched in December 2024 and entered operational phase during 2025, demonstrating world-first capabilities in precise formation flight and enabling an artificial solar eclipse in orbit to observe the Sun’s corona. TEKEVER’s contribution supports the mission’s formation flying communications and coordination needs, helping unlock a new class of future missions requiring high-precision multi-spacecraft operations.
