AirTRx 30Ka Business Aviation SATCOM
Orbit Communication Systems
The AirTRx family delivers reliable, high-speed connectivity across a range of midsize, super midsize (SMS) and large business jets. It serves VIP transportation, private jets, government agencies, and fleet operators with regional and global coverage. Key attributes include a two Line Replaceable Units (LRUs) terminal configuration, a real 3-axis system (elevation, tilt, azimuth) for continuous […]
Typed specifications8 values
Discloses 3 of 10 fields engineers filter by in this category (category median 3).
- Frequency band
- Ka full commercial Ka band support · datasheet p.1 Ka Tx/Rx | Ka
- Mass
- 10 000 g max · weight on tail, less than 22 lbs./10Kg · datasheet p.1
- Polarization
- dual dual polarization support for Tx/Rx · datasheet p.1
- Data interface
- other ARINC 429 · datasheet p.1 Ethernet MODMAN in-cabin network
- Reflector diameter
- 0.3 m 12-inch (30 cm) antenna · datasheet p.1
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier2 lines, in the manufacturer's own wording
- Frequency
- Ku-band or full ITU Ka-band
- Interface
- Ethernet/Serial/ARINC429
About
The AirTRx family delivers reliable, high-speed connectivity across a range of midsize, super midsize (SMS) and large business jets. It serves VIP transportation, private jets, government agencies, and fleet operators with regional and global coverage. Key attributes include a two Line Replaceable Units (LRUs) terminal configuration, a real 3-axis system (elevation, tilt, azimuth) for continuous tracking without ‘key hole’ limitations, superb EIRP spectral density with optimized size, weight, and power, aircraft INS stabilization compatibility, Ethernet, Serial, and ARINC429 interfaces, continuous polarization compensation for Ku-band, 4-port RF front-end support in Ka-band, multiple installation options (tail, fuselage, hatch), a built-in advanced control loop with step-track technology, a radome-covered design for all-weather operation, and multiple configurations from L- to K-band in a single platform.
Documentation
Need the full ICD, test reports or a specific revision? Ask the supplier directly.
