GaN C SSPA/BUC 800W 2:1 Redundancy System Indoor
TTI Norte
A 2:1 redundancy system for C-band satellite communication, featuring three 800W GaN SSPA/BUC units for enhanced reliability and continuous operation.
Typed specifications1 values
Discloses 0 of 8 fields engineers filter by in this category (category median 2).
- Envelope (L×W×H)
- 19” Rack 42 U (H) x 1 m (D) product page
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier7 lines, in the manufacturer's own wording
- System configuration
- 2:1 Redundancy
- Gan high power transmitter
- GaN SSPA/BUC C 800 W (Qty 3)
- Dual wg switches
- (Qty 2)
- Redundancy system controller
- Standard controller (indoor)
- Sub rack
- 2U-high 19” sub rack (indoor)
- Cabling
- AC cables (1.5 m long) (qty 2), RF cabling (Coaxial SMA-SMA/SMA-N cables from switches to SSPAs/BUCs (qty 3), Coaxial SMA-SMA cable from switch 1 to switch 2 (qty 1)), System cabling (AC cables (SSPAs/BUCs) (qty 3), M&C cables (SSPAs/BUCs) (qty 3), M&C cables (switches) (qty 2))
- Dimensions
- 19” Rack 42 U (H) x 1 m (D)
About
This 2:1 Redundancy System for C-band GaN SSPA/BUC 800W is designed for indoor use, providing high availability for critical satellite communication links. It includes three 800W GaN SSPA/BUC units, a redundancy WG assembly outdoor kit, WG sections, WG loads, two dual WG switches, and a redundancy system controller. The system is housed in a 2U-high 19” sub rack with dual internal power supplies and includes all necessary cabling. Key features include robust redundancy performance, a web interface for remote control, and user-friendly configuration/operation. The entire system is designed for rack mounting in a 19” Rack 42 U (H) x 1 m (D) cabinet.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
