IOI-8 Input/Output Interfaces Module
Innoflight
3U VPX Ethernet I/O module with four 2.5GBase-T and four 1000Base-T ports, 501 g and 7 W.
Key figurescomparable across the catalogue
- Mass
- 0.501 kg
- Power
- 7 W
- TRL
- 9
Normalised to common units so this product can be compared with others in its category. The supplier's own wording is below.
As published by the supplier
- Interfaces
- 4x 2.5GBase-T (2.5 GbE), 4x 1000Base-T (GbE)
- Form factor
- 3U VPX module 171 x 100 x 24 mm
- Mass
- 501 g
- Power
- 7 W
- TRL / MRL
- 9 / 10
- Flight heritage
- Since 2025
About
The IOI-8 provides Ethernet Input / Output Interfaces (IOI) in a 3U VPX module.
Overview: Ethernet input / output interfaces.
Key characteristics: 4x 2.5GBase-T (2.5 GbE) and 4x 1000Base-T (GbE) interfaces.
Size, weight and power: 3U VPX module 171 x 100 x 24 mm, 501 g, 7 W. Technology and manufacturing readiness are TRL 9 / MRL 10, with flight heritage since 2025. The IOI-8 is also used as the interface module inside the MNE-405 and MNE-410 Mission Networking Electronics chassis.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
