ASTRO APS Autonomous Star Sensor
Jena-Optronik
Heritage autonomous star sensor for LEO-GEO-deep space: <1/18yr lifetime, >470 units contracted including NASA Orion/Artemis.
Typed specifications8 values
Discloses 4 of 12 fields engineers filter by in this category (category median 8).
- Mass
- 2 000 g as published, mode unspecified · vendor page (catalogue a
- Envelope (L×W×H)
- 154 x 154 x 237 mm (incl. baffle) product page
- Sun exclusion angle
- 26 ° product page
- Field of view
- 20 ° product page
- Supply voltage
- 28 V as published, mode unspecified · vendor page (catalogue a
- Power consumption
- 6 W as published, mode unspecified · vendor page (catalogue a
- Operating temperature
- -30–60 °C as published, mode unspecified · vendor page (catalogue a
- Design lifetime
- 18 years as published, mode unspecified · vendor page (catalogue a
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier19 lines, in the manufacturer's own wording
- Field of view
- 20 deg circular
- Optics
- Refractive, 43 mm focal length, f/1.2, rad-hard glass
- Detector
- 1024x1024 px; HAS2 or STAR1000 APS CMOS
- Attitude random error xy (1-sigma)
- <1 arcsec
- Attitude random error z (1-sigma)
- <8 arcsec
- Bias error
- <5 arcsec (all axes)
- Sampling rate
- 10 Hz (up to 32 Hz on demand)
- Acquisition time
- <10s switch-on; <5s re-acquisition
- Max slew rate
- 3.0-5.0 deg/s (detector dependent)
- Sensitivity
- 6.0 mi
- Mass
- ~2 kg (incl. baffle, GEO shielding, DC/DC, MIL-1553)
- Dimensions
- 154 x 154 x 237 mm (incl. baffle)
- Power
- <6 W (Peltier OFF); <12 W (Peltier ON)
- Supply voltage
- 28 V, 50 V, 100 V
- Interface
- MIL-STD-1553B, RS422
- Sun exclusion angle
- 26 deg half-cone
- Operating temperature
- -30 to +60 deg C
- Design lifetime
- >18 years
- TRL
- 9 (~200 units in space, Orion/Artemis flight heritage)
About
The Jena-Optronik ASTRO APS is an autonomous star sensor using radiation-hard CMOS APS detector technology, designed for all mission scenarios including LEO, MEO, HEO, GEO, and deep space/crewed missions. With integrated optics and electronics in a single housing (154x154x237mm including baffle), the ASTRO APS delivers less than 1 arcsec (1-sigma) random error across-boresight and less than 8 arcsec boresight, with bias error under 5 arcsec. Sampling rate is 10 Hz (up to 32 Hz available); acquisition time is less than 10s on switch-on and less than 5s for re-acquisition. Supports HAS2 and STAR1000 APS CMOS detectors. Over 470 units contracted with approximately 200 in space. Notable missions include Alphasat (first flight 2013), NASA Orion/Artemis I and II, and the Roman Space Telescope.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
