D-SP6X-L-1W
NPC Spacemind
The D-SP6X-L-1W is a deployable solar panel with a single wing lateral configuration, compatible with 6U/12U CubeSat structures, offering high-efficiency triple junction solar cells and integrated sensors.
Typed specifications6 values
Discloses 1 of 12 fields engineers filter by in this category (category median 3).
- Output power (BOL)
- 18.4–20 W product page 18.4–20 W
- Form factor (as printed)
- XY side product page
- Supply voltage
- 20.8–22 V product page
- Power consumption
- 18.4–20 W product page
- Connector
- 4 parallel picoblade product page
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier15 lines, in the manufacturer's own wording
- Deployable solar panel for
- XY side
- Configuration
- 1 Wing Lateral
- Compatibility
- 6U/12U CubeSat structures
- Solar cells
- High efficiency triple junction UTJ
- Peak power
- 18.4 - 20 W
- Max power current
- 1 - 1.04 A
- Max power voltage
- 18.4 - 20 V
- Open circuit voltage
- 20.8 - 22 V
- Power connectors
- 4 parallel picoblade
- Option
- to add cells on the body fixed surface
- Customization options
- available
- Digital temperature sensor
- (SPI / I2C communication)
- Coarse sun sensors
- 2
- Inertial module
- (3D Acc + 3D Gyro)
- Magnetic sensor
- (3 axis)
About
The D-SP6X-L-1W is a deployable solar panel designed for the XY side of CubeSat structures. It features a 1-wing lateral configuration and is compatible with both 6U and 12U CubeSat platforms. The panel utilizes high-efficiency triple junction UTJ solar cells, providing a peak power output ranging from 18.4 to 20 W. It delivers a max power current of 1 to 1.04 A and a max power voltage of 18.4 to 20 V, with an open circuit voltage of 20.8 to 22 V. For power connectivity, it includes 4 parallel picoblade power connectors. The D-SP6X-L-1W offers customization options, including the ability to add additional solar cells on the body-fixed surface. Integrated sensors include a digital temperature sensor (supporting SPI / I2C communication), an NTC temperature sensor, two coarse sun sensors, an inertial module (comprising a 3D accelerometer and 3D gyroscope), and a 3-axis magnetic sensor. Alternative solar cell connection options are also available.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
