SmartLEO
OHB System AG
Flexible LEO satellite platform for Earth observation and reconnaissance missions, proven on SAR-Lupe and EnMAP.
Typed specifications29 values
Discloses 4 of 7 fields engineers filter by in this category (category median 3).
- Data interface
- MIL-STD-1553 standard data bus · datasheet p.3 CAN standard data bus | SpaceWire standard data bus
- Design lifetime
- 12 years max · design lifetime up to 12 years (overview table p.2: 3 – 12 ye… · datasheet p.3
- Orbit
- LEO typical orbit: Low Earth Orbit · datasheet p.3 SSO
- Max payload mass
- 400 kg max · payload maximum mass up to 400 kg · datasheet p.3
- Power available to payload
- 500 W average power payload · datasheet p.3
- Power generation (orbit average)
- 1 000 W max · solar generator up to 1 kW (BOL/EOL not stated) · datasheet p.3
- Attitude control
- 3-axis stabilised 3-axis control; star tracker, gyroscopes and reaction wheels … · datasheet p.3
- Pointing accuracy
- 0.01 ° nom. · typical 0.01° (scalable); slew rate typical 1°/s · datasheet p.3
- Propulsion
- included mono-propellant · datasheet p.3
- Payload data downlink rate
- 4 000 000 kbps max · Ka-Band data downlink · datasheet p.3 800 000 kbps max · X-Band data downlink
- Radio band
- Ka data downlink Ka-Band 4 Gbps · datasheet p.3 X data downlink X-Band 800 Mbps | S TM/TC S-Band 128/256 kbps
- Subsystems included
- ADCS 3-axis control: star tracker, gyroscopes, reaction wheels · datasheet p.3 Ka-band downlink data downlink Ka-Band 4 Gbps | X-band downlink data downlink X-Band 800 Mbps | thermal control MLI, heaters, sensors, heat-pipes | OBC on-board processor LEON II FT +3
- Max satellite wet mass
- 600–1 100 kg launch mass 600 – 1,100 kg · datasheet p.3
- Structure material
- other aluminium alloy Aluminum Sandwich Panel with Internal Shear Frame; panel desi… · datasheet p.3
- Material (as printed)
- Structure: Aluminum Sandwich Panel with Internal Shear Frame; Panel Design: Aluminum Honeycomb datasheet p.3
- Flight heritage
- SmartLEO inherits the flight-proven SAR-Lupe platform (five satellites, operational since December 2007); used for EnMAP hyper-spectral satellite datasheet p.3
Each value is typed with its unit and measurement condition and cites the datasheet page it was taken from. Nothing is guessed: a field that is absent here has not been published by the manufacturer. machine-extracted ✓ checked by NewSpace Market ✓ manufacturer confirmed by the manufacturer.
As published by the supplier4 lines, in the manufacturer's own wording
- Orbit
- Low Earth Orbit (LEO), including Sun-Synchronous Orbit (SSO)
- Typical mass range
- ~770–940 kg
- Typical orbit altitude
- 470–650 km
- Heritage missions
- SAR-Lupe constellation (5 satellites), EnMAP
About
SmartLEO is OHB System AG’s low-Earth-orbit satellite bus, designed for a wide range of remote sensing, reconnaissance, and science missions in sun-synchronous and other low-altitude orbits. The platform has been proven on two major operational programmes: the SAR-Lupe radar reconnaissance constellation (5 satellites, ~770 kg each, 470–505 km SSO) and the EnMAP hyperspectral Earth observation satellite (~936 kg, 638–651 km SSO).
SmartLEO features flexible mechanical and electrical interfaces allowing it to accommodate large synthetic aperture radar antennas and high-resolution optical spectrometers. Its modular architecture enables rapid adaptation to mission-specific requirements from science agencies, defence customers, and commercial operators.
